Display optional output
ports
Cables used for EMC testing
Ethernet Standard 8-pin RJ45 connector with unshielded
Ethernet cable - 7.6 m maximum length.
Ethernet Standard 8-pin RJ45 connector with unshielded
Ethernet cable - 7.6 m maximum length.
Universal Serial Bus
(USB)
Standard Type A connector USB cable with foil
shield - 1.8 m maximum length.
Universal Serial Bus
(USB)
The visible USB connector can be populated
with a memory stick.
Video Graphics Array
(VGA)
Standard VGA 15-pin D-subminiature three row
connector with shielded cable - 1.8 m maximum
length.
RS-232 Serial with On/
STBY
Part number 1009-5935-000.
Monitor On/STBY Standard 9-pin D-subminiature male connector
with shielded cable - 1.8 m maximum length.
Part number M1187043.
Guidance and manufacturer's declaration - electromagnetic
emissions
The system is suitable for use in the specified electromagnetic
environment. The customer and/or user of the system should assure
that it is used in an electromagnetic environment as described below.
.
Phenomenon Professional healthcare facility environment
Conducted and radiated RF emissions CISPR 11
Harmonic emissions IEC 61000-3-2 Not applicable
Voltage fluctuations/flicker emissions IEC
61000-3-3
Not applicable
The emissions characteristics of this equipment make it suitable for
use in industrial areas and hospitals (CISPR 11 class A). If it is used
in a residential environment (for which CISPR 11 class B is normally
required) this equipment might not offer adequate protection to radio-
frequency communication services. The user might need to take
mitigation measures, such as relocating or re-orienting the
equipment.
Note
11 Specifications and theory of operation
2076152-001 11-41
