11-2 170 Series Monitor Revision D
2003023-001
Technical Specifications: General Monitor
General Monitor
Table 11-1. General Monitor Specifications
Category Technical Specifications
Power Requirements
Nominal Line Voltage:
Line Frequency:
Power Consumption (maximum):
Monitor DC Input:
100–230 VAC
50/60 Hz (operates over 47–63 Hz)
≤30 VA
12 Vdc at 2.5 A
Physical Characteristics
Height:
Width:
Depth:
Weight:
5.75 in (14.6 cm)
16.75 in (42.5 cm)
10.0 in (25.4 cm)
8 lbs (3.6 kg) approx.
Environmental Conditions
Monitor:
Ambient Temperature:
Relative Humidity:
Strip Chart Paper
a
:
Ambient Temperature:
Relative Humidity:
a
Paper operating environmental conditions are for a period of less than one month. Paper storage environmental conditions are for extended storage.
Operating Storage
50°F to 104°F (10°C to 40°C) 14°F to 131°F (–10°C to 55°C)
10% to 75%, non-condensing 10% to 90%, non-condensing
50°F to 104°F (10°C to 40°C) < 80°F (< 26.5°C)
30% to 70%, non-condensing 45% to 65%, non-condensing
Certification
UL-2601.1:
CUL:
Designed to meet UL-2601.1
Medical electrical equipment classified by Underwriter’s Laboratories, Inc., with
respect to fire, shock, and mechanical hazards in accordance with UL-2601.1.
Classified with respect to electric shock, fire, mechanical, and other specified hazards
only, in accordance with CAN/CSA C22.2 No. 601.1
!
!
