11-4 170 Series Monitor Revision D
2003023-001
Technical Specifications: Strip Chart Recorder
Strip Chart Recorder
NOTE: Specifications subject to change without notice.
Table 11-3. Strip Chart Recorder Specifications
Heart Rate Scale
Chart Width:
Scaling:
Range:
Resolution:
Domestic International
7 cm 8 cm
30 BPM/cm 20 BPM/cm
30–240 BPM 50–210 BPM
1 BPM 1 BPM
Uterine Activity Scale
Chart Width:
Scaling:
Range:
Resolution:
Strain Gauge Tocotransducer
4 cm 4 cm
25 mmHg/cm 25 relative units/cm
0–100 mmHg 0–100 relative units
1 mmHg 1 relative unit
Recorder Drive
Speeds:
Speed Accuracy:
1, 2, and 3 cm/min
±2 % over 10 minutes
