Chapter 1. Installation
18 DigitalFlow™ XMT868i Startup Guide
1.7.5i Wiring the MODBUS/TCP Interface
Customers can also use a modified XMT868i that provides a MODBUS/TCP interface to communicate to an internal
network. An optional MODBUS/TCP card with a unique MAC (IP) address (installed only in slot 2) includes an RJ45
connector. To connect the MODBUS/TCP-enabled XMT868i to the network, insert the jack of an RJ45 cable into the
RJ45 connector, route the cable through one of the conduit holes using an appropriate cable clamp, and wire the other
end of the cable to the Ethernet network according to the manufacturers instructions (see Figure 12 on page 25).
Note: The MAC address for a specific XMT868i is included with customer documentation. For more information on
setting up the MAC address, refer to Chapter 6 of the Programming Manual.
1.7.5j Wiring the Ethernet Interface
A modified XMT868i can use the Ethernet interface to communicate to a local area network. An optional Ethernet card
with a unique MAC (IP) address (installed only in slot 2) includes an RJ45 connector. To connect the Ethernet-enabled
XMT868i to the network, insert the jack of an RJ45 cable into the RJ45 connector, route the cable through one of the
conduit holes using an appropriate cable clamp, and wire the other end of the cable to the Ethernet network according
to the manufacturers instructions. An external connection is required between the Ethernet option card and the
XMT868i’s RS232 connector, as shown in Table 4 below and Figure 12 on page 25.
Note: The MAC address for a specific XMT868i is included with customer documentation. For more information on
setting up the MAC address, refer to Appendix C of the Programming Manual.
Table 4: RS232 to Ethernet Interconnections
RS232 TB
on Rear PC Board
TB1
on Ethernet Card
TX Pin 1
RX Pin 2
COM Pin 3
