GE DVM1950 - Outer Casing Removal Procedure; Steps for Outer Cover Removal

– 20 –
7. Slide the outer cover back about 1 inch toward
the rear of the oven. Lift the cover from the
oven.
6. Remove 2 Phillips-head screws from the left side
of the oven.
5. Remove 4 Phillips-head screws from the right
side of the oven.
4. Remove 6 Phillips-head screws from the bottom
cover of the oven.
3. Remove 7 Phillips-head screws from the back of
the oven.
Outer Cover
To gain access to many of the microwave oven
components, it is necessary to remove the outer
cover.
WARNING: To prevent electrical shock, use extreme
caution when diagnosing oven with outer cover
removed and power ON. The high voltage section
of the power supply, including fi lament leads, has
the potential with respect to ground to reach 4000
Volts!
To remove the outer cover:
1. Remove the oven. (See Microwave
Oven
Removal
.)
2. Remove 4 Phillips-head screws from the top of
the oven.
