GEK-106310AB F650 Digital Bay Controller 4-41
4 HUMAN INTERFACES. SETTINGS & ACTUAL VALUES 4.2 HUMAN MACHINE INTERFACE (HMI)
4
To enter this menu press the shuttle key or enter key when the option Actual Values is selected in main menu. A secondary
level will be displayed with different sublevels as shown on Table 4.29:. Pressing Up/down keys or rotating the shuttle key,
(left for moving up and right for moving down) select the next level to be displayed, press the enter/shuttle key again to
enter in next level and press ESC key to return to previous level if desired. This navigation will be performed the same for
all the menus in Actual Values. Once the last sublevel is reached, move up and down to visualize the actual values
selected.
Metering >
Primary Values >
Current
Voltage
Power
Energy
Demand
Secondary Values >
Current
Voltage
Power
Frequency
Inputs/Outputs >
Contact Inputs >
Board F/ Board G/ Board H/ Board J
Cont. Output St. >
Board F/ Board G/ Board H/ Board J
Cont. Output Op. >
Board F/ Board G/ Board H/ Board J
Cont. Output Rs. >
Board F/ Board G/ Board H/ Board J
IO Board Status
Virtual Inputs >
Virtual Inp.Latched
Virtual Inp.SR
Virtual Outputs
Remote Outputs (for IEC61850 models
only) >
DNA
User St
GOOSE Dig Outputs
Remote Inputs for IEC61850 models
only)>
Remote Input
Remote Devices
GOOSE Dig Inputs
GOOSE Analog Inputs
Analog Inputs >
Board F/ Board G/ Board H/ Board J
