GEK-106310AB F650 Digital Bay Controller 7-43
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
7
2.6 Logical Nodes for metering and measurement. LN Group: M
2.6.1 MMTR (Metering)
Note: actVal in BCR is imlemented as INT32.
2.6.2 MMXU (Measurement)
MMTR class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
MMTR Metering
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Measured values
SupWh BCR Mapped to generic pulse counter O Pulse Counter 1
SupVArh BCR Mapped to generic pulse counter O Pulse Counter 2
DmdWh BCR Mapped to generic pulse counter O Pulse Counter 3
DmdVArh BCR Mapped to generic pulse counter O Pulse Counter 4
CntPsWh MV Positive Wat Counter O
CntNgWh MV Negative Wat Counter O
CntPsVArh MV Positive VAR Counter O
CntNgVArh MV Negative VAR Counter O
MMXU class
Attribute
Name
Attribute
Type
Explanation M/O/E Notes
MMXU Measurement
Data
Common Logical Node Information
Mod INC Mode M Status-only
Beh INS Behaviour M
Health INS Health M
NamPlt LPL Name plate M
Measured values
TotW MV Total active power (P) O Phase Real Pwr
TotVAr MV Total reactive power (Q) O Ph Reactive Pwr
TotVA MV Total apparent power (S) O Ph Apparent Pwr
TotPF MV Average power factor (PF) O 3 Ph Power Factor
Hz MV Frequency O Frequency
PPV DEL Phase to phase voltages (VL1L2,...) O Phase-to-Phase Primary
Voltages
PhV WYE Phase to ground voltages (VL1ER, ...) O Phase Primary Voltages
A WYE Phase currents (IL1, ...) O Phasor Primary
AuxV CMV Auxiliary Voltage E Vx Primary
BusHz MV Bus Frequency E Bus Frequency
