7-46 F650 Digital Bay Controller GEK-106310AB
7.2 IEC 61850 PROFILE FOR F650 7 IEC 61850 PROTOCOL
7
3 Enum types implementation
3.1 setCharact
Enum type : setCharact
Value Description supported new enum
value added
650 setting
internal
value
650 Relay curve
0- N - - -
1 ANSI Extremely Inverse Y - 11 ANSI Ext Inv
2 ANSI Very Inverse Y - 12 ANSI Very Inv
3 ANSI Normal Inverse Y - 13 ANSI Norm Inv
4 ANSI Moderately Inverse Y - 14 ANSI Mod Inv
5 ANSI Definite Time N - - -
6 Long-Time Extremely Inverse N - - -
7 Long-Time Very Inverse N - - -
8 Long-Time Inverse N - - -
9 IEC Normal Inverse Y - 3 IEC Curve A
10 IEC Very Inverse Y - 4 IEC Curve B
11 IEC Inverse N - - -
12 IEC Extremely Inverse Y - 5 IEC Curve C
13 IEC Short-Time Inverse Y - 7 IEC Short-Time Inv
14 IEC Long-Time Inverse Y - 6 IEC Long-Time Inv
15 IEC Definite Time Y - 16 Definite Time
16 Reserved N - - -
17 Definable curve 1 based on formula
[x=f(y,A,B,C,D,E,F)]
Y - 0 IEEE Ext Inv
18 Definable curve 2 based on formula
[x=f(y,A,B,C,D,E,F)]
Y - 1 IEEE Very Inv
19 Definable curve 3 based on formula
[x=f(y,A,B,C,D,E,F)]
Y - 2 IEEE Mod Inv
20 Definable curve 4 based on formula
[x=f(y,A,B,C,D,E,F)]
Y - 8 IAC Ext Inv
21 Definable curve 5 based on formula
[x=f(y,A,B,C,D,E,F)]
Y - 9 IAC Very Inv
22 Definable curve 6 based on formula
[x=f(y,A,B,C,D,E,F)]
Y - 10 IAC Mod Inv
23 Definable curve 7 based on formula
[x=f(y,A,B,C,D,E,F)]
Y- 15 I2t
24 Definable curve 8 based on formula
[x=f(y,A,B,C,D,E,F)]
Y - 17 Rectifier Curve
25 Definable curve 9 based on formula
[x=f(y,A,B,C,D,E,F)]
N- - -
26 Definable curve 10 based on formula
[x=f(y,A,B,C,D,E,F)]
N- - -
27 Definable curve 11 based on formula
[x=f(y,A,B,C,D,E,F)]
N- - -
28 Definable curve 12 based on formula
[x=f(y,A,B,C,D,E,F)]
N- - -
29 Definable curve 13 based on formula
[x=f(y,A,B,C,D,E,F)]
N- - -
30 Definable curve 14 based on formula
[x=f(y,A,B,C,D,E,F)]
N- - -
