7-48 F650 Digital Bay Controller GEK-106310AB
7.2 IEC 61850 PROFILE FOR F650 7 IEC 61850 PROTOCOL
7
3.3 PolQty
3.4 AutoRecSt
3.5 InMagTyp
3.6 RsMod
3.7 PolOpMod
Enum type : PolQty
Value Description supported new enum
value added
650 setting
internal
value
650 Relay Polarization
-2 Vendor specific quantity 2 Y Y 3 V0*IP
-1 Vendor specific quantity 1 Y Y 2 V0+IP
1None N - - -
2 Zero Sequence Current Y - 1 IP
3 Zero Sequence Voltage Y - 0 V0
4 Negative Sequence Voltage N - - -
5 Phase to Phase Voltages N - - -
6 Phase to Ground Voltages N - - -
Enum type : AutoRecSt
Value Description supported new enum
value added
Comments
-1 Definite Trip Y - Specified by Tissue 133
1 Ready Y -
2 In Progress Y -
3 Successful Y -
4 Unsuccessful Y - Specified by Tissue 3
Enum type : InMagTyp
Value Description supported new enum
value added
Value of 650 Relay setting
0 phasor Y Y PHASOR(DFT)
1rms Y Y RMS
Enum type : RsMod
Value Description supported new enum
value added
Value of 650 Relay setting
0 instantaneous Y Y INSTANTANEOUS
1lineal Y Y LINEAL
Enum type : PolOpMod
Value Description supported new enum
value added
Value of 650 Relay setting
0 reverse Y Y REVERSE
1forward Y Y FORWARD
