GEK-106310AB F650 Digital Bay Controller 7-49
7 IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
7
3.8 InMod
3.9 PhLogic
3.10 MaxNumShot
7.2.7.3.3 TICS FOR 650 FAMILY OF RELAYS
Reference documentation: “TICS for 650 family of relays v1_7 firm3_60”. This document describes the:
• Introduction
• TICS Template
1 Introduction
This document provides a template for the tissues conformance statement (TICS). According to the UCA QAP the TICS is
required to perform a conformance test and is referenced on the final certificate.
In this TICS template only tissues with a “green” status are considered since they become mandatory and thus must be
included in the UCA Device conformance test procedures.
“Green” Tissues listed in this document represent the current status of all Tissues for a date of the document creation.
As for some of the remaining tissues, they are not yet included in the test procedures, either because they are just a recom-
mendation or optional within the IEC 61850 documents, or because their respective proposals are not defined in such detail
to be implemented or tested, or because they are simply not applicable, just editorial, with no change for implementation
and testing.
The supported (“Sup”) column indicates:
• Y: yes, the tissue is implemented in the device.
• N: no, the tissue is not implemented in the device.
• N.A.: not applicable, the tissue is not applicable for the device.
Enum type : InMod
Value Description supported new enum
value added
Value of 650 Relay setting
0 phase-phase Y Y PHASE-PHASE
1 phase-ground Y Y PHASE-GROUND
Enum type : PhLogic
Value Description supported new enum
value added
Value of 650 Relay setting
0 any phase Y Y ANY PHASE
1 two phases Y Y TWO PHASES
2 all phases Y Y ALL PHASES
Enum type : MaxNumShot
Value Description supported new enum
value added
Value of 650 Relay setting
0 1 Shot Y Y 1
1 2 Shots Y Y 2
2 3 Shots Y Y 3
3 4 Shots Y Y 4
