7-70 F650 Digital Bay Controller GEK-106310AB
7.3 IEC 61850 CONFIGURATOR 7 IEC 61850 PROTOCOL
7
The definition of the Logical Node LLN0 is shown in 7.2.7.3.2. The rest of the mentioned Logical Nodes are affected in the
way that the setting data contained in those Logical Nodes have as many values as setting groups are defined, 3 for the
F650 relay.
Each setting data contained in those Logical Nodes has a type derived from one of the following common data classes
defined in the standard IEC 61850-7-3: ING, SPG, ASG and CURVE. The setting data attributes of these common data
classes have functional constraints SG (setting group) and SE (setting group editable) when the setting group function is
enabled and SP (setpoint) when it is not.
When the setting group function is enabled the F650 relay has the following instances of the Logical Nodes mentioned
before:
PIOC
Phase instantaneous overcurrent: SGphHiPIOC1 and SGphLoPIOC1
Neutral instantaneous overcurrent: SGndPIOC1
Ground instantaneous overcurrent: SGgndPIOC1
Sensitive ground instantaneous overcurrent: SGhsePIOC1
PTOC
Phase time overcurrent: SGphHiPTOC1 and SGphLoPTOC1
Neutral time overcurrent: SGndPTOC1
Ground time overcurrent: SGgndPTOC1
Sensitive ground time overcurrent: SGhsePTOC1
PTOF
Overfrequency: SGPTOF1
PTOV
Phase overvoltage: SGphsPTOV1
Auxiliary overvoltage: SGauxPTOV1
Neutral overvoltage: SGneuHiPTOV1 and SGneuLoPTOV1
PTUV
Phase undervoltage: SGphsPTUV1
Auxiliary undervoltage: SGauxPTUV1
PTUF
Underfrequency: SGPTUF1
RDIR
Phase directional element: SGphsRDIR1
Neutral directional element: SGndRDIR1
Ground directional element: SGgndRDIR1
Sensitive ground directional element: SGhseRDIR1
