Estados Imagen Térmica - Thermal Image States
0x01A4 0x0040 THERMAL1 BLOCK F001 R 1
0x01A4 0x0080 THERMAL1 A RST F001 R 1
0x01A5 0x0100 THERMAL1 B RST F001 R 1
0x01A5 0x0200 THERMAL1 C RST F001 R 1
0x01A5 0x0400 THERMAL1 ALARM F001 R 1
0x01A5 0x0800 THERMAL1 OP F001 R 1
0x01A5 0x1000 THERMAL1 A ALRM F001 R 1
0x01A5 0x2000 THERMAL1 A OP F001 R 1
0x01A5 0x4000 THERMAL1 B ALRM F001 R 1
0x01A5 0x8000 THERMAL1 B OP F001 R 1
0x01A5 0x0001 THERMAL1 C ALRM F001 R 1
0x01A5 0x0002 THERMAL1 C OP F001 R 1
0x01AA 0x0004 THERMAL2 BLOCK F001 R 1
0x01AA 0x0008 THERMAL2 A RST F001 R 1
0x01AA 0x0010 THERMAL2 B RST F001 R 1
0x01AA 0x0020 THERMAL2 C RST F001 R 1
0x01AA 0x0040 THERMAL2 ALARM F001 R 1
0x01AA 0x0080 THERMAL2 OP F001 R 1
0x01AB 0x0100 THERMAL2 A ALRM F001 R 1
0x01AB 0x0200 THERMAL2 A OP F001 R 1
0x01AB 0x0400 THERMAL2 B ALRM F001 R 1
0x01AB 0x0800 THERMAL2 B OP F001 R 1
0x01AB 0x1000 THERMAL2 C ALRM F001 R 1
0x01AB 0x2000 THERMAL2 C OP F001 R 1
0x01B0 0x4000 THERMAL3 BLOCK F001 R 1
0x01B0 0x8000 THERMAL3 A RST F001 R 1
0x01B0 0x0001 THERMAL3 B RST F001 R 1
0x01B0 0x0002 THERMAL3 C RST F001 R 1
0x01B0 0x0004 THERMAL3 ALARM F001 R 1
0x01B0 0x0008 THERMAL3 OP F001 R 1
0x01B0 0x0010 THERMAL3 A ALRM F001 R 1
0x01B0 0x0020 THERMAL3 A OP F001 R 1
0x01B0 0x0040 THERMAL3 B ALRM F001 R 1
0x01B0 0x0080 THERMAL3 B OP F001 R 1
0x01B1 0x0100 THERMAL3 C ALRM F001 R 1
0x01B1 0x0200 THERMAL3 C OP F001 R 1
Estados Unidad Direccional de Fases - Phase Directional States
0x01B6 0x0400 PHASE DIR1 BLK INP F001 R 1
0x01B6 0x0800 PHASE DIR1 BLOCK A F001 R 1
0x01B6 0x1000 PHASE DIR1 A OP F001 R 1
0x01B6 0x2000 PHASE DIR1 BLOCK B F001 R 1
0x01B6 0x4000 PHASE DIR1 B OP F001 R 1
0x01B6 0x8000 PHASE DIR1 BLOCK C F001 R 1
0x01B6 0x0001 PHASE DIR1 C OP F001 R 1
0x01BB 0x0002 PHASE DIR2 BLK INP F001 R 1
0x01BB 0x0004 PHASE DIR2 BLOCK A F001 R 1
0x01BB 0x0008 PHASE DIR2 A OP F001 R 1
0x01BB 0x0010 PHASE DIR2 BLOCK B F001 R 1
0x01BB 0x0020 PHASE DIR2 B OP F001 R 1
0x01BB 0x0040 PHASE DIR2 BLOCK C F001 R 1
0x01BB 0x0080 PHASE DIR2 C OP F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
