GEK-106310AB F650 Digital Bay Controller B-33
APPENDIX B B.7 MEMORY MAP
B
Estados Unidad Direccional de Fases - Phase Directional States(cont.)
0x01C1 0x0100 PHASE DIR3 BLK INP F001 R 1
0x01C1 0x0200 PHASE DIR3 BLOCK A F001 R 1
0x01C1 0x0400 PHASE DIR3 A OP F001 R 1
0x01C1 0x0800 PHASE DIR3 BLOCK B F001 R 1
0x01C1 0x1000 PHASE DIR3 B OP F001 R 1
0x01C1 0x2000 PHASE DIR3 BLOCK C F001 R 1
0x01C1 0x4000 PHASE DIR3 C OP F001 R 1
Estados Unidad Direccional de Neutro - Neutral Directional States
0x01C6 0x8000 NEUTRAL DIR1 BLK INP F001 R 1
0x01C6 0x0001 NEUTRAL DIR1 BLOCK F001 R 1
0x01C6 0x0002 NEUTRAL DIR1 OP F001 R 1
0x01CB 0x0004 NEUTRAL DIR2 BLK INP F001 R 1
0x01CB 0x0008 NEUTRAL DIR2 BLOCK F001 R 1
0x01CB 0x0010 NEUTRAL DIR2 OP F001 R 1
0x01D0 0x0020 NEUTRAL DIR3 BLK INP F001 R 1
0x01D0 0x0040 NEUTRAL DIR3 BLOCK F001 R 1
0x01D0 0x0080 NEUTRAL DIR3 OP F001 R 1
Estados Unidad Direccional de Tierra - Ground Directional States
0x01D6 0x0100 GROUND DIR1 BLK INP F001 R 1
0x01D6 0x0200 GROUND DIR1 BLOCK F001 R 1
0x01D6 0x0400 GROUND DIR1 OP F001 R 1
0x01DB 0x0800 GROUND DIR2 BLK INP F001 R 1
0x01DB 0x1000 GROUND DIR2 BLOCK F001 R 1
0x01DB 0x2000 GROUND DIR2 OP F001 R 1
0x01E0 0x4000 GROUND DIR3 BLK INP F001 R 1
0x01E0 0x8000 GROUND DIR3 BLOCK F001 R 1
0x01E0 0x0001 GROUND DIR3 OP F001 R 1
Estados Fallo de Interruptor - Breaker Failure States
0x01E5 0x0002 BKR FAIL INITIATE F001 R 1
0x01E5 0x0004 BKR FAIL NO CURRENT F001 R 1
0x01E5 0x0008 BKR FAIL SUPERVISION F001 R 1
0x01E5 0x0010 BKR FAIL HISET F001 R 1
0x01E5 0x0020 BKR FAIL LOWSET F001 R 1
0x01E5 0x0040 INTERNAL ARC F001 R 1
0x01E5 0x0080 BKR FAIL 2nd STEP F001 R 1
Estados Fallo de Fusible - Fuse failure States
0x01EB 0x0100 VT FUSE FAILURE F001 R 1
Estados Unidad de Sincronismo - Synchrocheck States
0x01F0 0x0200 Synchrocheck BLK INP F001 R 1
0x01F0 0x0400 Synchrocheck OP F001 R 1
0x01F0 0x0800 SYNCHK CLOSE PERM F001 R 1
0x01F0 0x1000 Synchrocheck COND OP F001 R 1
0x01F0 0x2000 DL-DB OPERATION F001 R 1
0x01F0 0x4000 DL-LB OPERATION F001 R 1
0x01F0 0x8000 LL-DB OPERATION F001 R 1
0x01F0 0x0001 SLIP CONDITION F001 R 1
0x01F0 0x0002 BUS FREQ > LINE FREQ F001 R 1
0x01F0 0x0004 BUS FREQ < LINE FREQ F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
