GE F650 - Page 605

B-36 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Estados Sobreintensidad Temporizada de Secuencia Negativa - Negative Sequence TOC States
0x024B 0x0800 NEG SEQ TOC1 BLOCK F001 R 1
0x024B 0x1000 NEG SEQ TOC1 PKP F001 R 1
0x024B 0x2000 NEG SEQ TOC1 OP F001 R 1
0x0250 0x4000 NEG SEQ TOC2 BLOCK F001 R 1
0x0250 0x8000 NEG SEQ TOC2 PKP F001 R 1
0x0250 0x0001 NEG SEQ TOC2 OP F001 R 1
0x0255 0x0002 NEG SEQ TOC3 BLOCK F001 R 1
0x0255 0x0004 NEG SEQ TOC3 PKP F001 R 1
0x0255 0x0008 NEG SEQ TOC3 OP F001 R 1
Estados Sobrefrecuencia - Overfrequency States
0x025A 0x0010 OVERFREQ1 BLOCK F001 R 1
0x025A 0x0020 OVERFREQ1 PKP F001 R 1
0x025A 0x0040 OVERFREQ1 OP F001 R 1
0x025F 0x0080 OVERFREQ2 BLOCK F001 R 1
0x0260 0x0100 OVERFREQ2 PKP F001 R 1
0x0260 0x0200 OVERFREQ2 OP F001 R 1
0x0265 0x0400 OVERFREQ3 BLOCK F001 R 1
0x0265 0x0800 OVERFREQ3 PKP F001 R 1
0x0265 0x1000 OVERFREQ3 OP F001 R 1
Estados Subfrecuencia - Underfrequency States
0x026A 0x2000 UNDERFREQ1 BLOCK F001 R 1
0x026A 0x4000 UNDERFREQ1 PKP F001 R 1
0x026A 0x8000 UNDERFREQ1 OP F001 R 1
0x026F 0x0001 UNDERFREQ2 BLOCK F001 R 1
0x026F 0x0002 UNDERFREQ2 PKP F001 R 1
0x026F 0x0004 UNDERFREQ2 OP F001 R 1
0x0274 0x0008 UNDERFREQ3 BLOCK F001 R 1
0x0274 0x0010 UNDERFREQ3 PKP F001 R 1
0x0274 0x0020 UNDERFREQ3 OP F001 R 1
Estados Calibración - Calibration States
0x0279 0x0040 FACTORY CALIBRATION F001 R 1
0x0279 0x0080 CALIBRATION ERROR F001 R 1
Estados Oscilografía - Oscillography States
0x027A 0x0100 OSC DIG CHANNEL 1 F001 R 1
0x027A 0x0200 OSC DIG CHANNEL 2 F001 R 1
0x027A 0x0400 OSC DIG CHANNEL 3 F001 R 1
0x027A 0x0800 OSC DIG CHANNEL 4 F001 R 1
0x027A 0x1000 OSC DIG CHANNEL 5 F001 R 1
0x027A 0x2000 OSC DIG CHANNEL 6 F001 R 1
0x027A 0x4000 OSC DIG CHANNEL 7 F001 R 1
0x027A 0x8000 OSC DIG CHANNEL 8 F001 R 1
0x027A 0x0001 OSC DIG CHANNEL 9 F001 R 1
0x027A 0x0002 OSC DIG CHANNEL 10 F001 R 1
0x027A 0x0004 OSC DIG CHANNEL 11 F001 R 1
0x027A 0x0008 OSC DIG CHANNEL 12 F001 R 1
0x027A 0x0010 OSC DIG CHANNEL 13 F001 R 1
0x027A 0x0020 OSC DIG CHANNEL 14 F001 R 1
0x027A 0x0040 OSC DIG CHANNEL 15 F001 R 1
0x027A 0x0080 OSC DIG CHANNEL 16 F001 R 1
0x027B 0x0100 OSCILLO TRIGGER F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
