APPENDIX B B.7 MEMORY MAP
B
Estados Localizador de Faltas - Fault Report States
0x0280 0x0200 FAULT REPORT TRIGG F001 R 1
0x0280 0x0400 CLEAR FAULT REPORTS F001 R 1
Agrupamiento de Funciones - Group States
0x028F 0x0400 GROUP 1 ACT ON F001 R 1
0x028F 0x0800 GROUP 2 ACT ON F001 R 1
0x028F 0x1000 GROUP 3 ACT ON F001 R 1
0x028F 0x2000 SETT GROUPS BLOCK F001 R 1
0x028F 0x4000 GROUP 1 BLOCKED F001 R 1
0x028F 0x8000 GROUP 2 BLOCKED F001 R 1
0x028F 0x0001 GROUP 3 BLOCKED F001 R 1
Canal por defecto - Default Channel (not used)
0x0294 0x0002 Default Channel F001 R 1
Estados Unidad de Conductor Roto - Broken Conductor
0x0294 0x0004 BROKEN CONDUCT1 BLK F001 R 1
0x0294 0x0008 BROKEN CONDUCT1 PKP F001 R 1
0x0294 0x0010 BROKEN CONDUCT1 OP F001 R 1
0x0299 0x0020 BROKEN CONDUCT2 BLK F001 R 1
0x0299 0x0040 BROKEN CONDUCT2 PKP F001 R 1
0x0299 0x0080 BROKEN CONDUCT2 OP F001 R 1
0x029F 0x0100 BROKEN CONDUCT3 BLK F001 R 1
0x029F 0x0200 BROKEN CONDUCT3 PKP F001 R 1
0x029F 0x0400 BROKEN CONDUCT3 OP F001 R 1
Estados Energía - Energy States
0x02A4 0x0800 FREEZE ENERGY CNT F001 R 1
0x02A4 0x1000 UNFREEZE ENERGY CNT F001 R 1
0x02A4 0x2000 RESET ENERGY CNT F001 R 1
Estados Unidad de Tierra Aislada - Isolated Ground States
0x02B8 0x4000 ISOLATED GND1 BLK F001 R 1
0x02B8 0x8000 ISOLATED GND1 PKP F001 R 1
0x02B8 0x0001 ISOLATED GND1 OP F001 R 1
0x02C7 0x0002 ISOLATED GND2 BLK F001 R 1
0x02C7 0x0004 ISOLATED GND2 PKP F001 R 1
0x02C7 0x0008 ISOLATED GND2 OP F001 R 1
0x02D6 0x0010 ISOLATED GND3 BLK F001 R 1
0x02D6 0x0020 ISOLATED GND3 PKP F001 R 1
0x02D6 0x0040 ISOLATED GND3 OP F001 R 1
Estados Unidad Direccional de Tierra Sensible - Sensitive Ground Directional States
0x02E5 0x0080 SENS GND DIR1 BLK IP F001 R 1
0x02E6 0x0100 SENS GND DIR1 BLOCK F001 R 1
0x02E6 0x0200 SENS GND DIR1 OP F001 R 1
0x02EB 0x0400 SENS GND DIR2 BLK IP F001 R 1
0x02EB 0x0800 SENS GND DIR2 BLOCK F001 R 1
0x02EB 0x1000 SENS GND DIR2 OP F001 R 1
0x02F0 0x2000 SENS GND DIR3 BLK IP F001 R 1
0x02F0 0x4000 SENS GND DIR3 BLOCK F001 R 1
0x02F0 0x8000 SENS GND DIR3 OP F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
