GE F650 - Page 607

B-38 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Estados Unidad de Potencia Máxima Directa - Forward Power(32FP) States
0x02F5 0x0001 FWD PWR1 BLOCK F001 R 1
0x02F5 0x0002 FWD PWR1 STG1 PKP F001 R 1
0x02F5 0x0004 FWD PWR1 STG1 OP F001 R 1
0x02F5 0x0008 FWD PWR1 STG2 PKP F001 R 1
0x02F5 0x0010 FWD PWR1 STG2 OP F001 R 1
0x02FA 0x0020 FWD PWR2 BLOCK F001 R 1
0x02FA 0x0040 FWD PWR2 STG1 PKP F001 R 1
0x02FA 0x0080 FWD PWR2 STG1 OP F001 R 1
0x02FB 0x0100 FWD PWR2 STG2 PKP F001 R 1
0x02FB 0x0200 FWD PWR2 STG2 OP F001 R 1
0x0300 0x0400 FWD PWR3 BLOCK F001 R 1
0x0300 0x0800 FWD PWR3 STG1 PKP F001 R 1
0x0300 0x1000 FWD PWR3 STG1 OP F001 R 1
0x0300 0x2000 FWD PWR3 STG2 PKP F001 R 1
0x0300 0x4000 FWD PWR3 STG2 OP F001 R 1
Entradas Demanda - Demand Inputs
0x0305 0x8000 DEMAND TRIGGER INP F001 R 1
0x0305 0x0001 DEMAND RESET INP F001 R 1
Estado Entradas Tarjeta H (32 elementos) - Board H: Contact Input States
0x0319 0x0002 CONT IP_H_CC1 F001 R 1
0x0319 0x0004 CONT IP_H_CC2 F001 R 1
... ... ... ... ... ... ... ...
0x031B 0x0001 CONT IP_H_CC32 F001 R 1
Estado Señales Activación salidas Tarjeta H (16 elementos) - Board H: Contact Output Operate -logical States-
0x031B 0x0002 CONT OP OPER_H_01 F001 R 1
0x031B 0x0004 CONT OP OPER_H_02 F001 R 1
... ... ... ... ... ... ... ...
0x031C 0x0001 CONT OP OPER_H_16 F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
