GE F650 - Page 608

GEK-106310AB F650 Digital Bay Controller B-39
APPENDIX B B.7 MEMORY MAP
B
Estado Señales Reposición de Salidas Tarjeta H (16 elementos) - Board H: Contact Output Resets
0x031C 0x0002 CONT OP RESET_H_01 F001 R 1
0x031C 0x0004 CONT OP RESET_H_02 F001 R 1
... ... ... ... ... ... ... ...
0x031D 0x0001 CONT OP RESET_H_16 F001 R 1
Estado Salidas Tarjeta H (16 elementos) - Board H: Contact Outputs -physical States-
0x031D 0x0002 CONT OP_H_01 F001 R 1
0x031D 0x0004 CONT OP_H_02 F001 R 1
... ... ... ... ... ... ... ...
0x031E 0x0001 CONT OP_H_16 F001 R 1
Estado Tarjeta H - Board H Status
0x031E 0x0002 BOARD H STATUS F001 R 1
Estado Entradas Tarjeta J (32 elementos) - Board J: Contact Input States
0x033E 0x0004 CONT IP_J_CC1 F001 R 1
0x033E 0x0008 CONT IP_J_CC2 F001 R 1
... ... ... ... ... ... ... ...
0x0340 0x0002 CONT IP_J_CC32 F001 R 1
Estado Señales Activación salidas Tarjeta J (16 elementos) - Board J: Contact Output Operate -logical States-
0x0340 0x0004 CONT OP OPER_J_01 F001 R 1
0x0340 0x0008 CONT OP OPER_J_02 F001 R 1
... ... ... ... ... ... ... ...
0x0341 0x0002 CONT OP OPER_J_16 F001 R 1
Estado Señales Reposición de Salidas Tarjeta J (16 elementos) - Board J: Contact Output Resets
0x0341 0x0004 CONT OP RESET_J_01 F001 R 1
0x0341 0x0008 CONT OP RESET_J_02 F001 R 1
... ... ... ... ... ... ... ...
0x0342 0x0002 CONT OP RESET_J_16 F001 R 1
Estado Salidas Tarjeta J (16 elementos) - Board J: Contact Outputs -physical states-
0x0342 0x0004 CONT OP_J_01 F001 R 1
0x0342 0x0008 CONT OP_J_02 F001 R 1
... ... ... ... ... ... ... ...
0x0343 0x0002 CONT OP_J_16 F001 R 1
Estado Tarjeta J - Board J Status
0x0343 0x0004 BOARD J STATUS F001 R 1
Estados Sobrecorriente Temporizada de Fases Nivel Bajo - Phase TOC Low States
0x0363 0x0008 PH TOC1 LOW A BLK F001 R 1
0x0363 0x0010 PH TOC1 LOW B BLK F001 R 1
0x0363 0x0020 PH TOC1 LOW C BLK F001 R 1
0x0363 0x0040 PH TOC1 LOW A PKP F001 R 1
0x0363 0x0080 PH TOC1 LOW A OP F001 R 1
0x0364 0x0100 PH TOC1 LOW B PKP F001 R 1
0x0364 0x0200 PH TOC1 LOW B OP F001 R 1
0x0364 0x0400 PH TOC1 LOW C PKP F001 R 1
0x0364 0x0800 PH TOC1 LOW C OP F001 R 1
0x0364 0x1000 PH TOC1 LOW PKP F001 R 1
0x0364 0x2000 PH TOC1 LOW OP F001 R 1
0x0369 0x4000 PH TOC2 LOW A BLK F001 R 1
0x0369 0x8000 PH TOC2 LOW B BLK F001 R 1
0x0369 0x0001 PH TOC2 LOW C BLK F001 R 1
0x0369 0x0002 PH TOC2 LOW A PKP F001 R 1
0x0369 0x0004 PH TOC2 LOW A OP F001 R 1
0x0369 0x0008 PH TOC2 LOW B PKP F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
