GEK-106310AB F650 Digital Bay Controller B-41
APPENDIX B B.7 MEMORY MAP
B
Estados Aparamenta (16 elementos) - Switchgear States
0x0378 0x0010 SWITCH 1 OPEN F001 R 1
0x0378 0x0020 SWITCH 1 CLOSED F001 R 1
0x0378 0x0040 SWITCH 1 00_ERROR F001 R 1
0x0378 0x0080 SWITCH 1 11_ERROR F001 R 1
0x0379 0x0100 SWITCH 2 OPEN F001 R 1
0x0379 0x0200 SWITCH 2 CLOSED F001 R 1
0x0379 0x0400 SWITCH 2 00_ERROR F001 R 1
0x0379 0x0800 SWITCH 2 11_ERROR F001 R 1
... ... ... ... ... ... ... ...
0x037C 0x0001 SWITCH 16 OPEN F001 R 1
0x037C 0x0002 SWITCH 16 CLOSED F001 R 1
0x037C 0x0004 SWITCH 16 00_ERROR F001 R 1
0x037C 0x0008 SWITCH 16 11_ERROR F001 R 1
Estados Inicio Apertura y Cierre Aparamenta - Switchgear Open-Close Initializing States
0x037C 0x0010 SWITCH 1 OPEN INIT F001 R 1
0x037C 0x0020 SWITCH 1 CLOSE INIT F001 R 1
0x037C 0x0040 SWITCH 2 OPEN INIT F001 R 1
0x037C 0x0080 SWITCH 2 CLOSE INIT F001 R 1
... ... ... ... ... ... ... ...
0x037E 0x0004 SWITCH 16 OPEN INIT F001 R 1
0x037E 0x0008 SWITCH 16 CLOSE INIT F001 R 1
Estados Fallo Apertura y Cierre Aparamenta - Switchgear Fail States
0x037E 0x0010 SWGR 1 FAIL TO OPEN F001 R 1
0x037E 0x0020 SWGR 2 FAIL TO OPEN F001 R 1
... ... ... ... ... ... ... ...
0x037F 0x0008 SWGR 16 FAIL TO OPEN F001 R 1
0x037F 0x0010 SWGR 1 FAIL TO CLOSE F001 R 1
0x037F 0x0020 SWGR 2 FAIL TO CLOSE F001 R 1
... ... ... ... ... ... ... ...
0x0380 0x0008 SWGR 16 FAIL TO CLOSE F001 R 1
Estados Interruptor - Breaker States
0x0390 0x0010 KI2t PHASE A ALARM F001 R 1
0x0390 0x0020 KI2t PHASE B ALARM F001 R 1
0x0390 0x0040 KI2t PHASE C ALARM F001 R 1
0x0390 0x0080 BKR OPENINGS ALARM F001 R 1
0x0391 0x0100 BKR OPEN 1 HOUR ALRM F001 R 1
0x0391 0x0200 BREAKER OPEN F001 R 1
0x0391 0x0400 BREAKER CLOSED F001 R 1
0x0391 0x0800 BREAKER UNDEFINED F001 R 1
0x0391 0x1000 RESET KI2t COUNTERS F001 R 1
0x0391 0x2000 RESET BKR COUNTERS F001 R 1
Estado Mapa Usuario - User Map State
0x039B 0x4000 USER MAP STATUS F001 R 1
Estado Curvas Usuario - Flex Curves States
0x039B 0x8000 FLEXCURVE A STATUS F001 R 1
0x03A0 0x0001 FLEXCURVE B STATUS F001 R 1
0x03A5 0x0002 FLEXCURVE C STATUS F001 R 1
0x03AA 0x0004 FLEXCURVE D STATUS F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
