B-42 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Estados Internos Sistema - Internal System States
0x03B1 0x0008 Green Zone F001 R 1
0x03B1 0x0010 Yellow Zone F001 R 1
0x03B1 0x0020 Orange Zone F001 R 1
0x03B1 0x0040 Red Zone F001 R 1
Estados Unidad direccional de potencia - Directional Power States
0x03B2 0x8000 DIR PWR1 BLOCK F001 R 1
0x03B2 0x0001 DIR PWR1 STG1 PKP F001 R 1
0x03B2 0x0002 DIR PWR1 STG1 OP F001 R 1
0x03B2 0x0004 DIR PWR1 STG2 PKP F001 R 1
0x03B2 0x0008 DIR PWR1 STG2 OP F001 R 1
0x03B2 0x0010 DIR PWR1 STG PKP F001 R 1
0x03B2 0x0020 DIR PWR1 STG OP F001 R 1
0x03B7 0x0040 DIR PWR2 BLOCK F001 R 1
0x03B7 0x0080 DIR PWR2 STG1 PKP F001 R 1
0x03B8 0x0100 DIR PWR2 STG1 OP F001 R 1
0x03B8 0x0200 DIR PWR2 STG2 PKP F001 R 1
0x03B8 0x0400 DIR PWR2 STG2 OP F001 R 1
0x03B8 0x0800 DIR PWR2 STG PKP F001 R 1
0x03B8 0x1000 DIR PWR2 STG OP F001 R 1
0x03BD 0x2000 DIR PWR3 BLOCK F001 R 1
0x03BD 0x4000 DIR PWR3 STG1 PKP F001 R 1
0x03BD 0x8000 DIR PWR3 STG1 OP F001 R 1
0x03BD 0x0001 DIR PWR3 STG2 PKP F001 R 1
0x03BD 0x0002 DIR PWR3 STG2 OP F001 R 1
0x03BD 0x0004 DIR PWR3 STG PKP F001 R 1
0x03BD 0x0008 DIR PWR3 STG OP F001 R 1
Estados Unidad de Rotor Bloqueado - Locked Rotor (48)
0x03C2 0x0010 LOCKED ROTOR1 BLK F001 R 1
0x03C2 0x0020 LOCKED ROTOR1 PKP F001 R 1
0x03C2 0x0040 LOCKED ROTOR1 OP F001 R 1
0x03C3 0x0080 LOCKED ROTOR2 BLK F001 R 1
0x03C4 0x0100 LOCKED ROTOR2 PKP F001 R 1
0x03C4 0x0200 LOCKED ROTOR2 OP F001 R 1
0x03C5 0x0400 LOCKED ROTOR3 BLK F001 R 1
0x03C5 0x0800 LOCKED ROTOR3 PKP F001 R 1
0x03C5 0x1000 LOCKED ROTOR3 OP F001 R 1
Estados Salidas Remotas DNA - DNA Remote Output Status
0x03E5 0x0008 DNA 1 F001 R 1
0x03E5 0x0010 DNA 2 F001 R 1
... ... ... ... ... ... ... ...
0x03E7 0x0004 DNA 32 F001 R 1
Estados Salidas Remotas Usuario - UserSt Remote Output Status
0x03E7 0x0008 UserSt 1 F001 R 1
0x03E5 0x0010 UserSt 2 F001 R 1
... ... ... ... ... ... ... ...
0x03EB 0x0004 UserSt 64 F001 R 1
Estados Entradas Remotas - Remote Inputs Status
0x03EB 0x0008 Remote Input 1 F001 R 1
0x03EB 0x0010 Remote Input 2 F001 R 1
... ... ... ... ... ... ... ...
0x03ED 0x0004 Remote Input 32 F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
