GEK-106310AB F650 Digital Bay Controller B-43
APPENDIX B B.7 MEMORY MAP
B
Estados Dispositivos Remotos - Remote Devices Status
0x03ED 0x0008 Remote Device 1 F001 R 1
0x03ED 0x0010 Remote Device 2 F001 R 1
... ... ... ... ... ... ... ...
0x03EE 0x0004 Remote Device 32 F001 R 1
Estados Sicronizacion Remota - SNTP/IRIG B Status(Do not apply to C650 models)
0x03F2 0x0008 SNTP FAILURE F001 R 1
0x03F2 0x0010 IRIGB FAILURE F001 R 1
Comparadores analógicos-Analog Comparators
0x03F8 0x0020 Analog Level 01 F001 R 1
0x03F8 0x0040 Analog Level 02 F001 R 1
0x03F8 0x0080 Analog Level 03 F001 R 1
0x03F9 0x0100 Analog Level 04 F001 R 1
0x03F9 0x0200 Analog Level 05 F001 R 1
0x03F9 0x0400 Analog Level 06 F001 R 1
0x03F9 0x0800 Analog Level 07 F001 R 1
0x03F9 0x1000 Analog Level 08 F001 R 1
0x03F9 0x2000 Analog Level 09 F001 R 1
0x03F9 0x4000 Analog Level 10 F001 R 1
0x03F9 0x8000 Analog Level 11 F001 R 1
0x03F9 0x0001 Analog Level 12 F001 R 1
0x03F9 0x0002 Analog Level 13 F001 R 1
0x03F9 0x0004 Analog Level 14 F001 R 1
0x03F9 0x0008 Analog Level 15 F001 R 1
0x03F9 0x0010 Analog Level 16 F001 R 1
0x03F9 0x0020 Analog Level 17 F001 R 1
0x03F9 0x0040 Analog Level 18 F001 R 1
0x03F9 0x0080 Analog Level 19 F001 R 1
0x03FA 0x0100 Analog Level 20 F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
