B-44 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Estados Derivada de Frecuencia - Frequency Rate of Change States
0x03FC 0x0002 FREQ RATE1 BLOCK F001 R 1
0x03FC 0x0004 FREQ RATE1 PKP F001 R 1
0x03FC 0x0008 FREQ RATE1 OP F001 R 1
0x0401 0x0010 FREQ RATE2 BLOCK F001 R 1
0x0401 0x0020 FREQ RATE2 PKP F001 R 1
0x0401 0x0040 FREQ RATE2 OP F001 R 1
0x0406 0x0080 FREQ RATE3 BLOCK F001 R 1
0x0407 0x0100 FREQ RATE3 PKP F001 R 1
0x0407 0x0200 FREQ RATE3 OP F001 R 1
0x03FC 0x0002 FREQ RATE1 BLOCK F001 R 1
0x03FC 0x0004 FREQ RATE1 PKP F001 R 1
0x03FC 0x0008 FREQ RATE1 OP F001 R 1
0x0401 0x0010 FREQ RATE2 BLOCK F001 R 1
0x0401 0x0020 FREQ RATE2 PKP F001 R 1
0x0401 0x0040 FREQ RATE2 OP F001 R 1
0x0406 0x0080 FREQ RATE3 BLOCK F001 R 1
0x0407 0x0100 FREQ RATE3 PKP F001 R 1
0x0407 0x0200 FREQ RATE3 OP F001 R 1
Estados función inversión de carga-Load Encroachment Status
0x040C 0x0400 LOAD ENCR1 BLOCK F001 R 1
0x040C 0x0800 LOAD ENCR1 PKP F001 R 1
0x040C 0x1000 LOAD ENCR1 OP F001 R 1
0x0411 0x2000 LOAD ENCR2 BLOCK F001 R 1
0x0411 0x4000 LOAD ENCR2 PKP F001 R 1
0x0411 0x8000 LOAD ENCR2 OP F001 R 1
0x0416 0x0001 LOAD ENCR3 BLOCK F001 R 1
0x0416 0x0002 LOAD ENCR3 PKP F001 R 1
0x0416 0x0002 LOAD ENCR3 PKP F001 R 1
0x0416 0x0004 LOAD ENCR3 OP F001 R 1
Entradas digitales GOOSE-Rem GOOSE digital Inputs
0x0421 0x2000 Rem GOOSE Dig Inp 1 F001 R 1
0x0421 0x4000 Rem GOOSE Dig Inp 2 F001 R 1
0x0421 0x8000 Rem GOOSE Dig Inp 3 F001 R 1
0x0421 0x0001 Rem GOOSE Dig Inp 4 F001 R 1
0x0421 0x0002 Rem GOOSE Dig Inp 5 F001 R 1
0x0421 0x0004 Rem GOOSE Dig Inp 6 F001 R 1
0x0421 0x0008 Rem GOOSE Dig Inp 7 F001 R 1
0x0421 0x0010 Rem GOOSE Dig Inp 8 F001 R 1
0x0421 0x0020 Rem GOOSE Dig Inp 9 F001 R 1
0x0421 0x0040 Rem GOOSE Dig Inp 10 F001 R 1
0x0421 0x0080 Rem GOOSE Dig Inp 11 F001 R 1
0x0422 0x0100 Rem GOOSE Dig Inp 12 F001 R 1
0x0422 0x0200 Rem GOOSE Dig Inp 13 F001 R 1
0x0422 0x0400 Rem GOOSE Dig Inp 14 F001 R 1
0x0422 0x0800 Rem GOOSE Dig Inp 15 F001 R 1
0x0422 0x1000 Rem GOOSE Dig Inp 16 F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
