GEK-106310AB F650 Digital Bay Controller B-45
APPENDIX B B.7 MEMORY MAP
B
Entradas digitales GOOSE-Rem GOOSE digital Inputs(cont.)
0x0422 0x2000 Rem GOOSE Dig Inp 17 F001 R 1
0x0422 0x4000 Rem GOOSE Dig Inp 18 F001 R 1
0x0422 0x8000 Rem GOOSE Dig Inp 19 F001 R 1
0x0422 0x0001 Rem GOOSE Dig Inp 20 F001 R 1
0x0422 0x0002 Rem GOOSE Dig Inp 21 F001 R 1
0x0422 0x0004 Rem GOOSE Dig Inp 22 F001 R 1
0x0422 0x0008 Rem GOOSE Dig Inp 23 F001 R 1
0x0422 0x0010 Rem GOOSE Dig Inp 24 F001 R 1
0x0422 0x0020 Rem GOOSE Dig Inp 25 F001 R 1
0x0422 0x0040 Rem GOOSE Dig Inp 26 F001 R 1
0x0422 0x0080 Rem GOOSE Dig Inp 27 F001 R 1
0x0423 0x0100 Rem GOOSE Dig Inp 28 F001 R 1
0x0423 0x0200 Rem GOOSE Dig Inp 29 F001 R 1
0x0423 0x0400 Rem GOOSE Dig Inp 30 F001 R 1
0x0423 0x0800 Rem GOOSE Dig Inp 31 F001 R 1
0x0423 0x1000 Rem GOOSE Dig Inp 32 F001 R 1
Salidas digitales GOOSE-Remote GOOSE digital Outputs
0x0423 0x2000 Rem GOOSE Dig Out 1 F001 R 1
0x0423 0x4000 Rem GOOSE Dig Out 2 F001 R 1
0x0423 0x8000 Rem GOOSE Dig Out 3 F001 R 1
0x0423 0x0001 Rem GOOSE Dig Out 4 F001 R 1
0x0423 0x0002 Rem GOOSE Dig Out 5 F001 R 1
0x0423 0x0004 Rem GOOSE Dig Out 6 F001 R 1
0x0423 0x0008 Rem GOOSE Dig Out 7 F001 R 1
0x0423 0x0010 Rem GOOSE Dig Out 8 F001 R 1
0x0423 0x0020 Rem GOOSE Dig Out 9 F001 R 1
0x0423 0x0040 Rem GOOSE Dig Out 10 F001 R 1
0x0423 0x0080 Rem GOOSE Dig Out 11 F001 R 1
0x0424 0x0100 Rem GOOSE Dig Out 12 F001 R 1
0x0424 0x0200 Rem GOOSE Dig Out 13 F001 R 1
0x0424 0x0400 Rem GOOSE Dig Out 14 F001 R 1
0x0424 0x0800 Rem GOOSE Dig Out 15 F001 R 1
0x0424 0x1000 Rem GOOSE Dig Out 16 F001 R 1
0x0424 0x2000 Rem GOOSE Dig Out 17 F001 R 1
0x0424 0x4000 Rem GOOSE Dig Out 18 F001 R 1
0x0424 0x8000 Rem GOOSE Dig Out 19 F001 R 1
0x0424 0x0001 Rem GOOSE Dig Out 20 F001 R 1
0x0424 0x0002 Rem GOOSE Dig Out 21 F001 R 1
0x0424 0x0004 Rem GOOSE Dig Out 22 F001 R 1
0x0424 0x0008 Rem GOOSE Dig Out 23 F001 R 1
0x0424 0x0010 Rem GOOSE Dig Out 24 F001 R 1
0x0424 0x0020 Rem GOOSE Dig Out 25 F001 R 1
0x0424 0x0040 Rem GOOSE Dig Out 26 F001 R 1
0x0424 0x0080 Rem GOOSE Dig Out 27 F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
