B-46 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Salidas digitales GOOSE-Remote GOOSE digital Outputs(cont.)
0x0425 0x0100 Rem GOOSE Dig Out 28 F001 R 1
0x0425 0x0200 Rem GOOSE Dig Out 29 F001 R 1
0x0425 0x0400 Rem GOOSE Dig Out 30 F001 R 1
0x0425 0x0800 Rem GOOSE Dig Out 31 F001 R 1
0x0425 0x1000 Rem GOOSE Dig Out 32 F001 R 1
Estados Función 32N (Nivel Alto y Nivel Bajo) - wattmetric Ground Fault Status (High and Low Level)
0x0450 0x0080 32N1 HIGH BLOCK F001 R 1
0x0451 0x0100 32N1 HIGH PKP F001 R 1
0x0451 0x0200 32N1 HIGH OC PKP F001 R 1
0x0451 0x0400 32N1 HIGH OP F001 R 1
0x0452 0x0800 32N2 HIGH BLOCK F001 R 1
0x0452 0x1000 32N2 HIGH PKP F001 R 1
0x0452 0x2000 32N2 HIGH OC PKP F001 R 1
0x0452 0x4000 32N2 HIGH OP F001 R 1
0x0453 0x8000 32N3 HIGH BLOCK F001 R 1
0x0453 0x0001 32N3 HIGH PKP F001 R 1
0x0453 0x0002 32N3 HIGH OC PKP F001 R 1
0x0453 0x0004 32N3 HIGH OP F001 R 1
0x0454 0x0008 32N1 LOW BLOCK F001 R 1
0x0454 0x0010 32N1 LOW PKP F001 R 1
0x0454 0x0020 32N1 LOW OC PKP F001 R 1
0x0454 0x0040 32N1 LOW OP F001 R 1
0x0455 0x0080 32N2 LOW BLOCK F001 R 1
0x0456 0x0100 32N2 LOW PKP F001 R 1
0x0456 0x0200 32N2 LOW OC PKP F001 R 1
0x0456 0x0400 32N2 LOW OP F001 R 1
0x0457 0x0800 32N3 LOW BLOCK F001 R 1
0x0457 0x1000 32N3 LOW PKP F001 R 1
0x0457 0x2000 32N3 LOW OC PKP F001 R 1
0x0457 0x4000 32N3 LOW OP F001 R 1
Entradas Analógicas (Tarjetas F y G)- Analog Inputs (F and G boards)(Do not apply to C650 models)
0x0B06 ANALOG_INP_F_01 F002 1000 R 2
0x0B08 ANALOG_INP_F_02 F002 1000 R 2
... ... ... ... ... ... ...
0x0B14 ANALOG_INP_F_08 F002 1000 R 2
0x0B86 ANALOG_INP_G_01 F002 1000 R 2
0x0B88 ANALOG_INP_G_02 F002 1000 R 2
... ... ... ... ... ... ...
0x0B94 ANALOG_INP_G_08 F002 1000 R 2
Medidas en Valores Secundarios - Analog measures in Secondary Values
0x0C00 Phasor Ia F002 1000 R 2
0x0C02 RMS Ia F002 1000 R 2
0x0C04 Ia Real F002 1000 R 2
0x0C06 Ia Imag F002 1000 R 2
0x0C08 Phasor Ib F002 1000 R 2
0x0C0A RMS Ib F002 1000 R 2
0x0C0C Ib Real F002 1000 R 2
0x0C0E Ib Imag F002 1000 R 2
0x0C10 Phasor Ic F002 1000 R 2
0x0C12 RMS Ic F002 1000 R 2
0x0C14 Ic Real F002 1000 R 2
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
