GEK-106310AB F650 Digital Bay Controller B-47
APPENDIX B B.7 MEMORY MAP
B
Medidas en Valores Secundarios - Analog measures in Secondary Values(cont.)
0x0C16 Ic Imag F002 1000 R 2
0x0C18 Phasor In F002 1000 R 2
0x0C1A In Real F002 1000 R 2
0x0C1C In Imag F002 1000 R 2
0x0C1E Phasor Ig F002 1000 R 2
0x0C20 RMS Ig F002 1000 R 2
0x0C22 Ig Real F002 1000 R 2
0x0C24 Ig Imag F002 1000 R 2
0x0C26 Phasor Isg F002 1000 R 2
0x0C28 RMS Isg F002 1000 R 2
0x0C2A Isg Real F002 1000 R 2
0x0C2C Isg Imag F002 1000 R 2
0x0C2E Zero seq I0 F002 1000 R 2
0x0C30 I0 Real F002 1000 R 2
0x0C32 I0 Imag F002 1000 R 2
0x0C34 Positive Seq I1 F002 1000 R 2
0x0C36 I1 Real F002 1000 R 2
0x0C38 I1 Imag F002 1000 R 2
0x0C3A Negative Seq I2 F002 1000 R 2
0x0C3C I2 Real F002 1000 R 2
0x0C3E I2 Imag F002 1000 R 2
0x0C40 Phasor Vab F002 1000 R 2
0x0C42 Vab Real F002 1000 R 2
0x0C44 Vab Imag F002 1000 R 2
0x0C46 Phasor Vbc F002 1000 R 2
0x0C48 Vbc Real F002 1000 R 2
0x0C4A Vbc Imag F002 1000 R 2
0x0C4C Phasor Vca F002 1000 R 2
0x0C4E Vca Real F002 1000 R 2
0x0C50 Vca Imag F002 1000 R 2
0x0C52 Phasor Van F002 1000 R 2
0x0C54 Va Real F002 1000 R 2
0x0C56 Va Imag F002 1000 R 2
0x0C58 Phasor Vbn F002 1000 R 2
0x0C5A Vb Real F002 1000 R 2
0x0C5C Vb Imag F002 1000 R 2
0x0C5E Phasor Vcn F002 1000 R 2
0x0C60 Vc Real F002 1000 R 2
0x0C62 Vc Imag F002 1000 R 2
0x0C64 Phasor Vn F002 1000 R 2
0x0C66 Vn Real F002 1000 R 2
0x0C68 Vn Imag F002 1000 R 2
0x0C6A Positive Seq V1 F002 1000 R 2
0x0C6C V1 Real F002 1000 R 2
0x0C6E V1 Imag F002 1000 R 2
0x0C70 Negative Seq V2 F002 1000 R 2
0x0C72 V2 Real F002 1000 R 2
0x0C74 V2 Imag F002 1000 R 2
0x0C76 Zero Seq V0 F002 1000 R 2
0x0C78 V0 Real F002 1000 R 2
0x0C7A V0 Imag F002 1000 R 2
0x0C7C Phasor Vx F002 1000 R 2
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
