B-48 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Medidas en Valores Secundarios - Analog measures in Secondary Values(cont.)
0x0C7E Vx Real F002 1000 R 2
0x0C80 Vx Imag F002 1000 R 2
0x0C82 Nominal Voltage F002 1000 R 2
0x0C84 VL Real F002 1000 R 2
0x0C86 VL Imag F002 1000 R 2
0x0C88 VBB Real F002 1000 R 2
0x0C8A VBB Imag F002 1000 R 2
0x0C8C Line Voltage F002 1000 R 2
0x0C8E Bus Voltage F002 1000 R 2
0x0C90 Line Frequency F002 1000 R 2
0x0C92 Bus Frequency F002 1000 R 2
0x0C94 Phase A Apparent Pwr F002 1000 R 2
0x0C96 Phase B Apparent Pwr F002 1000 R 2
0x0C98 Phase C Apparent Pwr F002 1000 R 2
0x0C9A Phase A Real Pwr F002 1000 R 2
0x0C9C Phase B Real Pwr F002 1000 R 2
0x0C9E Phase C Real Pwr F002 1000 R 2
0x0CA0 Phase A Reactive Pwr F002 1000 R 2
0x0CA2 Phase B Reactive Pwr F002 1000 R 2
0x0CA4 Phase C Reactive Pwr F002 1000 R 2
0x0CA6 3 Phase Apparent Pwr F002 1000 R 2
0x0CA8 3 Phase Real Pwr F002 1000 R 2
0x0CAA 3 Phase Reactive Pwr F002 1000 R 2
0x0CAC Phase A Power Factor F002 1000 R 2
0x0CAE Phase B Power Factor F002 1000 R 2
0x0CB0 Phase C Power Factor F002 1000 R 2
0x0CB2 3 Phase Power Factor F002 1000 R 2
Ratios corriente y tensión - Current and Voltage Ratios
0x0CB4 CT Ratio F002 1000 R 2
0x0CB6 CT Ratio Ig F002 1000 R 2
0x0CB8 CT Ratio Isg F002 1000 R 2
0x0CBA PT Ratio F002 1000 R 2
Angulos - Angles
0x0CBC Ia Angle F002 1000 R 2
0x0CBE Ib Angle F002 1000 R 2
0x0CC0 Ic Angle F002 1000 R 2
0x0CC2 In Angle F002 1000 R 2
0x0CC4 Ig Angle F002 1000 R 2
0x0CC6 Isg Angle F002 1000 R 2
0x0CC8 Va Angle F002 1000 R 2
0x0CCA Vb Angle F002 1000 R 2
0x0CCC Vc Angle F002 1000 R 2
0x0CCE Vn Angle F002 1000 R 2
0x0CD0 Vx Angle F002 1000 R 2
0x0CD2 Vab Angle F002 1000 R 2
0x0CD4 Vbc Angle F002 1000 R 2
0x0CD6 Vca Angle F002 1000 R 2
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
