GEK-106310AB F650 Digital Bay Controller B-49
APPENDIX B B.7 MEMORY MAP
B
Frequency rate of change value
0x0CD8 df/dt F002 1000
0
R2
Versión del HMI - HMI Version
0x0CE2 HMI Version F004 1000 R 1
0x0CE3 DISPLAY TYPE F004 1000 R 1
Valores Imagen Térmica - Thermal Image Values
0x0DD9 THERMAL1 IMAGE A F003 1 R 2
0x0DDB THERMAL1 IMAGE B F003 1 R 2
0x0DDD THERMAL1 IMAGE C F003 1 R 2
0x0DE4 THERMAL2 IMAGE A F003 1 R 2
0x0DE6 THERMAL2 IMAGE B F003 1 R 2
0x0DE8 THERMAL2 IMAGE C F003 1 R 2
0x0DEF THERMAL3 IMAGE A F003 1 R 2
0x0DF1 THERMAL3 IMAGE B F003 1 R 2
0x0DF3 THERMAL3 IMAGE C F003 1 R 2
Diferencia de tensión para la función de sincronismo-Voltage Difference for synchrocheck unit
0x0E31 VOLTAGE DIFFERENCE F002 1000
0
R2
Diferencia de Frecuencia para la función de sincronismo-Frequency Difference for synchrocheck unit
0x0E33 FREQ. DIFFERENCE F002 1000
0
R2
Estados Reenganchador (Enumerado) - Autorecloser Status
0x0E36 AR STATUS F012 R 1 0=OUT OF SERVICE
1=READY
2=LOCKOUT
3=BLOCK
4=RECLOSE IN PROGRESS
0x0E37 AR LOCKOUT MODE F012 R 1 0=NONE
1=ANOMALY
2=FAIL TO OPEN
3=FAIL TO CLOSE
4=MANUAL
5=NO CONDITIONS
6=MAX NUMBER OF TRIPS
7=LAST SHOT
0x0E38 AR BLOCK MODE F012 R 1 0=NONE
1=LEVEL
2=PULSE
3=LEVEL+PULSE
Estados Oscilografía - Oscillography States
0x0EB6 NUMBER OF TRIGGERS F004 1 R 1
0x0EB7 CYCLES PER RECORD F004 1 R 1
0x0EB8 AVAILABLE RECORDS F004 1 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
