B-50 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Estados Localizador de Faltas - Fault Report States
0x0EBB FAULT DATE F011 R 3
0x0EBE FAULT TYPE F012 R 1 0=GROUND
1=PHASE
2=3 PH
3=AG
4=ABG
5=AB
6=BG
7=BCG
8=BC
9=CG
10=CAG
11=CA
12=NAF
0x0EBF FAULT LOCATION F003 1 R 2
0x0EC1 FAULT REPORT NUMBER F005 1 R 2
Medidas en Valores Primarios - Analog measures in Primary Values
0x0EE2 Phasor Ia Primary F002 1000 R 2
0x0EE4 Phasor Ib Primary F002 1000 R 2
0x0EE6 Phasor Ic Primary F002 1000 R 2
0x0EE8 Phasor Ig Primary F002 1000 R 2
0x0EEA Phasor Isg Primary F002 1000 R 2
0x0EEC Phasor In Primary F002 1000 R 2
0x0EEE RMS Ia Primary F002 1000 R 2
0x0EF0 RMS Ib Primary F002 1000 R 2
0x0EF2 RMS Ic Primary F002 1000 R 2
0x0EF4 RMS Ig Primary F002 1000 R 2
0x0EF6 RMS Isg Primary F002 1000 R 2
0x0EF8 I0 Primary F002 1000 R 2
0x0EFA I1 Primary F002 1000 R 2
0x0EFC I2 Primary F002 1000 R 2
0x0EFE V0 Primary F002 1000 R 2
0x0F00 V1 Primary F002 1000 R 2
0x0F02 V2 Primary F002 1000 R 2
0x0F04 Vab Primary F002 1000 R 2
0x0F06 Vbc Primary F002 1000 R 2
0x0F08 Vca Primary F002 1000 R 2
0x0F0A Va Primary F002 1000 R 2
0x0F0C Vb Primary F002 1000 R 2
0x0F0E Vc Primary F002 1000 R 2
0x0F10 Vn Primary F002 1000 R 2
0x0F12 Vx Primary F002 1000 R 2
0x0F14 VBB Primary F002 1000 R 2
0x0F16 VL Primary F002 1000 R 2
0x0F18 Phase A Real Pwr F002 1000 R 2
0x0F1A Phase A Reactive Pwr F002 1000 R 2
0x0F1C Phase A Apparent Pwr F002 1000 R 2
0x0F1E Phase B Real Pwr F002 1000 R 2
0x0F20 Phase B Reactive Pwr F002 1000 R 2
0x0F22 Phase B Apparent Pwr F002 1000 R 2
0x0F24 Phase C Real Pwr F002 1000 R 2
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
