GEK-106310AB F650 Digital Bay Controller B-51
APPENDIX B B.7 MEMORY MAP
B
Medidas en Valores Primarios - Analog measures in Primary Values(cont.)
0x0F26 Phase C Reactive Pwr F002 1000 R 2
0x0F28 Phase C Apparent Pwr F002 1000 R 2
0x0F2A 3 Phase Real Pwr F002 1000 R 2
0x0F2C 3 Phase Reactive Pwr F002 1000 R 2
0x0F2E 3 Phase Apparent Pwr F002 1000 R 2
0x0F30 Phase A Power Factor F002 1000 R 2
0x0F32 Phase B Power Factor F002 1000 R 2
0x0F34 Phase C Power Factor F002 1000 R 2
0x0F36 3 Phase Power Factor F002 1000 R 2
0x0F38 Line Frequency F002 1000 R 2
0x0F3A Bus Frequency F002 1000 R 2
0x0F3C Positive MWatthour F002 1000 R 2
0x0F3E Negative MWatthour F002 1000 R 2
0x0F40 Positive MVarhour F002 1000 R 2
0x0F42 Negative MVarhour F002 1000 R 2
0x0F44 Pos MWatthour Cnt F002 1000 R 2
0x0F46 Neg MWatthour Cnt F002 1000 R 2
0x0F48 Pos MVarhour Cnt F002 1000 R 2
0x0F4A Neg MVarhour Cnt F002 1000 R 2
0x0F4C % of Load-To-Trip F002 1000 R 2
Medidas Demanda - Demand measures
0x0FAB DEMAND IA F002 1000 R 2
0x0FAD DEMAND IA MAX F002 1000 R 2
0x0FAF DEMAND IA DATE F011 R 3
0x0FB2 DEMAND IB F002 1000 R 2
0x0FB4 DEMAND IB MAX F002 1000 R 2
0x0FB6 DEMAND IB DATE F011 R 3
0x0FB9 DEMAND IC F002 1000 R 2
0x0FBB DEMAND IC MAX F002 1000 R 2
0x0FBD DEMAND IC DATE F011 R 3
0x0FC0 DEMAND IG F002 1000 R 2
0x0FC2 DEMAND IG MAX F002 1000 R 2
0x0FC4 DEMAND IG DATE F011 R 3
0x0FC7 DEMAND ISG F002 1000 R 2
0x0FC9 DEMAND ISG MAX F002 1000 R 2
0x0FCB DEMAND ISG DATE F011 R 3
0x0FCE DEMAND I2 F002 1000 R 2
0x0FD0 DEMAND I2 MAX F002 1000 R 2
0x0FD2 DEMAND I2 DATE F011 R 3
0x0FD5 DEMAND W F002 1000 R 2
0x0FD7 DEMAND W MAX F002 1000 R 2
0x0FD9 DEMAND W DATE F011 R 3
0x0FDC DEMAND VAR PWR F002 1000 R 2
0x0FDE DEMAND VAR MAX F002 1000 R 2
0x0FE0 DEMAND VAR DATE F011 R 3
0x0FE3 DEMAND VA PWR F002 1000 R 2
0x0FE5 DEMAND VA MAX F002 1000 R 2
0x0FE7 DEMAND VA DATE F011 R 3
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
