B-52 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Entradas Analógicas (Tarjetas J y H)- Analog Inputs (J and H boards)
0x0FFE ANALOG_INP_H_01 F002 1000 R 2
0x1000 ANALOG_INP_H_02 F002 1000 R 2
... ... ... ... ... ... ...
0x100C ANALOG_INP_H_08 F002 1000 R 2
0x107E ANALOG_INP_J_01 F002 1000 R 2
0x1080 ANALOG_INP_J_02 F002 1000 R 2
... ... ... ... ... ... ...
0x108C ANALOG_INP_J_08 F002 1000 R 2
Contadores de Interruptor - Breaker Counters
0x111D BREAKER OPENINGS F005 1 R 2
0x111F BREAKER CLOSINGS F005 1 R 2
0x1121 KI2t PHASE A F003 1 R 2
0x1123 KI2t PHASE B F003 1 R 2
0x1125 KI2t PHASE C F003 1 R 2
0x1127 BKR OPENING TIME F003 1 R 2
0x1129 BKR CLOSING TIME F003 1 R 2
0x112B BKR OPEN TIMING F003 1 R 2
0x112D BKR CLOSE TIMING F003 1 R 2
Registrador de Datos - Data Logger
0x1153 OLDEST SAMPLE TIME F011 R 3
0x1156 NEWEST SAMPLE TIME F011 R 3
0x1159 DATA LOGGER CHANNELS F004 1 R 1
0x115A DATA LOGGER DAYS F003 1 R 2
Estados Internos Sistema - Internal System States
0x1160 Kswapd Time F005 1 R 2
0x1162 mtd2 Time F005 1 R 2
0x1164 mtd3 Time F005 1 R 2
0x1166 CPU Rtai F005 1 R 2
0x1168 CPU Linux F005 1 R 2
0x116A Total RAM F005 1024 R 2
0x116C Used DRAM F005 1024 R 2
0x116E Free RAM F005 1024 R 2
0x1170 Shared RAM F005 1024 R 2
0x1172 Buffer RAM F005 1024 R 2
0x1174 Cached RAM F005 1024 R 2
0x1176 Green Counter F005 1 R 2
0x1178 Yellow Counter F005 1 R 2
0x117A Orange Counter F005 1 R 2
0x117C Red Counter F005 1 R 2
0x117E UpTime F005 1 R 2
0x120E ICD STATUS F012 R 1 0=UNKNOWN
1=ICD ERROR
2=MODIFIED
3=IN PROGRESS
4=OK WITHOUT DAIS
5=OK
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
