B-54 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Medidas Potencia Función 32N (Nivel Alto y Bajo) - wattmetric Ground Fault Power Measurements (High and Low Level)
0x1349 32N1 HIGH POWER F002 1000 R 2
0x1350 32N2 HIGH POWER F002 1000 R 2
0x1357 32N3 HIGH POWER F002 1000 R 2
0x135E 32N1 LOW POWER F002 1000 R 2
0x1365 32N2 LOW POWER F002 1000 R 2
0x136C 32N3 LOW POWER F002 1000 R 2
Funciones Protección habilitadas - Protection Summary
0x2204 0x0001 Phase IOC1 High F001 R 1
0x2220 0x0001 Phase IOC2 High F001 R 1
0x223C 0x0001 Phase IOC3 High F001 R 1
0x2258 0x0001 Phase IOC1 Low F001 R 1
0x2274 0x0001 Phase IOC2 Low F001 R 1
0x2290 0x0001 Phase IOC3 Low F001 R 1
0x22AC 0x0001 Neutral IOC1 F001 R 1
0x22C7 0x0001 Neutral IOC2 F001 R 1
0x22E2 0x0001 Neutral IOC3 F001 R 1
0x22FD 0x0001 Ground IOC1 F001 R 1
0x2319 0x0001 Ground IOC2 F001 R 1
0x2335 0x0001 Ground IOC3 F001 R 1
0x2351 0x0001 Sensitive Ground IOC1 F001 R 1
0x236D 0x0001 Sensitive Ground IOC2 F001 R 1
0x2389 0x0001 Sensitive Ground IOC3 F001 R 1
0x23A5 0x0001 Phase TOC1 High F001 R 1
0x23C2 0x0001 Phase TOC2 High F001 R 1
0x23DF 0x0001 Phase TOC3 High F001 R 1
0x23FC 0x0001 Neutral TOC1 F001 R 1
0x2417 0x0001 Neutral TOC2 F001 R 1
0x2432 0x0001 Neutral TOC3 F001 R 1
0x244D 0x0001 Ground TOC1 F001 R 1
0x2469 0x0001 Ground TOC2 F001 R 1
0x2485 0x0001 Ground TOC3 F001 R 1
0x24A1 0x0001 Sensitive Ground TOC1 F001 R 1
0x24BD 0x0001 Sensitive Ground TOC2 F001 R 1
0x24D9 0x0001 Sensitive Ground TOC3 F001 R 1
0x24F5 0x0001 Phase UV1 F001 R 1
0x2514 0x0001 Phase UV2 F001 R 1
0x2533 0x0001 Phase UV3 F001 R 1
0x2552 0x0001 Negative Sequence OV1 F001 R 1
0x256D 0x0001 Negative Sequence OV2 F001 R 1
0x2588 0x0001 Negative Sequence OV3 F001 R 1
0x25A3 0x0001 Thermal Model1 F001 R 1
0x25C0 0x0001 Thermal Model2 F001 R 1
0x25DD 0x0001 Thermal Model3 F001 R 1
0x25FA 0x0001 Phase Directional1 F001 R 1
0x2615 0x0001 Phase Directional2 F001 R 1
0x2630 0x0001 Phase Directional3 F001 R 1
0x264B 0x0001 Neutral Directional1 F001 R 1
0x2667 0x0001 Neutral Directional2 F001 R 1
0x2683 0x0001 Neutral Directional3 F001 R 1
0x269F 0x0001 Ground Directional1 F001 R 1
0x26BB 0x0001 Ground Directional2 F001 R 1
0x26D7 0x0001 Ground Directional3 F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
