GE F650 - Page 624

GEK-106310AB F650 Digital Bay Controller B-55
APPENDIX B B.7 MEMORY MAP
B
Funciones Protección habilitadas - Protection Summary(cont)
0x26F3 0x0001 Breaker Failure F001 R 1
0x271C 0x0001 Fuse Failure F001 R 1
0x2731 0x0001 Synchrocheck F001 R 1
0x2763 0x0001 Recloser F001 R 1
0x278C 0x0001 Neutral OV1 High F001 R 1
0x27A7 0x0001 Neutral OV2 High F001 R 1
0x27C2 0x0001 Neutral OV3 High F001 R 1
0x27DD 0x0001 Neutral OV1 Low F001 R 1
0x27F8 0x0001 Neutral OV2 Low F001 R 1
0x2813 0x0001 Neutral OV3 Low F001 R 1
0x282E 0x0001 Auxiliary UV1 F001 R 1
0x2848 0x0001 Auxiliary UV2 F001 R 1
0x2862 0x0001 Auxiliary UV3 F001 R 1
0x287C 0x0001 Phase OV1 F001 R 1
0x2898 0x0001 Phase OV2 F001 R 1
0x28B4 0x0001 Phase OV3 F001 R 1
0x28D0 0x0001 Auxiliary OV1 F001 R 1
0x28EB 0x0001 Auxiliary OV2 F001 R 1
0x2906 0x0001 Auxiliary OV3 F001 R 1
0x2921 0x0001 Negative Sequence TOC1 F001 R 1
0x293C 0x0001 Negative Sequence TOC2 F001 R 1
0x2957 0x0001 Negative Sequence TOC3 F001 R 1
0x2972 0x0001 Overfrequency1 F001 R 1
0x298F 0x0001 Overfrequency2 F001 R 1
0x29AC 0x0001 Overfrequency3 F001 R 1
0x29C9 0x0001 Underfrequency1 F001 R 1
0x29E6 0x0001 Underfrequency2 F001 R 1
0x2A03 0x0001 Underfrequency3 F001 R 1
0x2A7C 0x0001 Oscillography F001 R 1
0x2A93 0x0001 Fault Report F001 R 1
0x2C08 0x0001 Broken Conductor1 F001 R 1
0x2C21 0x0001 Broken Conductor2 F001 R 1
0x2C3A 0x0001 Broken Conductor3 F001 R 1
0x2DF6 0x0001 Isolated Ground IOC1 F001 R 1
0x2E17 0x0001 Isolated Ground IOC2 F001 R 1
0x2E38 0x0001 Isolated Ground IOC3 F001 R 1
0x2E59 0x0001 Sensitive Ground Directional1 F001 R 1
0x2E74 0x0001 Sensitive Ground Directional2 F001 R 1
0x2E8F 0x0001 Sensitive Ground Directional3 F001 R 1
0x2EAA 0x0001 Forward power1 F001 R 1
0x2EC9 0x0001 Forward power2 F001 R 1
0x2EE8 0x0001 Forward power3 F001 R 1
0x2F07 0x0001 Demand F001 R 1
0x2F20 0x0001 IEC104 Protocol F001 R 1
0x32A5 0x0001 Phase TOC1 Low F001 R 1
0x32C2 0x0001 Phase TOC2 Low F001 R 1
0x32DF 0x0001 Phase TOC3 Low F001 R 1
0x38D4 0x0001 Data Logger F001 R 1
0x38FA 0x0001 Directional Power1 F001 R 1
0x391D 0x0001 Directional Power2 F001 R 1
0x3940 0x0001 Directional Power3 F001 R 1
0x3963 0x0001 Locked Rotor1 F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
