B-56 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Funciones Protección habilitadas - Protection Summary(cont.)
0x3978 0x0001 Locked Rotor2 F001 R 1
0x398D 0x0001 Locked Rotor3 F001 R 1
0x4130 0x0001 Frequency Rate1 F001 R 1
0x4150 0x0001 Frequency Rate2 F001 R 1
0x4170 0x0001 Frequency Rate3 F001 R 1
0x4190 0x0001 Load Encroachment1 F001 R 1
0x41AF 0x0001 Load Encroachment2 F001 R 1
0x41CE 0x0001 Load Encroachment3 F001 R 1
0x44A0 0x0001 Watt Gnd Flt High 1 F001 R 1
0x44BB 0x0001 Watt Gnd Flt High 2 F001 R 1
0x44D6 0x0001 Watt Gnd Flt High 3 F001 R 1
0x44F1 0x0001 Watt Gnd Flt Low 1 F001 R 1
0x450C 0x0001 Watt Gnd Flt Low 2 F001 R 1
0x4527 0x0001 Watt Gnd Flt Low 3 F001 R 1
Funciones con Eventos habilitados - Snapshot Events Summary
0x1EE5 0x0001 Board F Event F001 R 1
0x208A 0x0001 Board G Event F001 R 1
0x2199 0x0001 General Settings Event F001 R 1
0x220C 0x0001 Phase IOC1 High Event F001 R 1
0x2228 0x0001 Phase IOC2 High Event F001 R 1
0x2244 0x0001 Phase IOC3 High Event F001 R 1
0x2260 0x0001 Phase IOC1 Low Event F001 R 1
0x227C 0x0001 Phase IOC2 Low Event F001 R 1
0x2298 0x0001 Phase IOC3 Low Event F001 R 1
0x22B3 0x0001 Neutral IOC1 Event F001 R 1
0x22CE 0x0001 Neutral IOC2 Event F001 R 1
0x22E9 0x0001 Neutral IOC3 Event F001 R 1
0x2305 0x0001 Ground IOC1 Event F001 R 1
0x2321 0x0001 Ground IOC2 Event F001 R 1
0x233D 0x0001 Ground IOC3 Event F001 R 1
0x2359 0x0001 Sensitive Ground IOC1 Event F001 R 1
0x2375 0x0001 Sensitive Ground IOC2 Event F001 R 1
0x2391 0x0001 Sensitive Ground IOC3 Event F001 R 1
0x23AE 0x0001 Phase TOC1 High Event F001 R 1
0x23CB 0x0001 Phase TOC2 High Event F001 R 1
0x23E8 0x0001 Phase TOC3 High Event F001 R 1
0x2403 0x0001 Neutral TOC1 Event F001 R 1
0x241E 0x0001 Neutral TOC2 Event F001 R 1
0x2439 0x0001 Neutral TOC3 Event F001 R 1
0x2455 0x0001 Ground TOC1 Event F001 R 1
0x2471 0x0001 Ground TOC2 Event F001 R 1
0x248D 0x0001 Ground TOC3 Event F001 R 1
0x24A9 0x0001 Sensitive Ground TOC1 Event F001 R 1
0x24C5 0x0001 Sensitive Ground TOC2 Event F001 R 1
0x24E1 0x0001 Sensitive Ground TOC3 Event F001 R 1
0x2500 0x0001 Phase UV1 Event F001 R 1
0x251F 0x0001 Phase UV2 Event F001 R 1
0x253E 0x0001 Phase UV3 Event F001 R 1
0x2559 0x0001 Negative Sequence OV1 Event F001 R 1
0x2574 0x0001 Negative Sequence OV2 Event F001 R 1
0x258F 0x0001 Negative Sequence OV3 Event F001 R 1
0x25AC 0x0001 Thermal Model1 Event F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
