GEK-106310AB F650 Digital Bay Controller B-57
APPENDIX B B.7 MEMORY MAP
B
Funciones con Eventos habilitados - Snapshot Events Summary(cont.)
0x25C9 0x0001 Thermal Model2 Event F001 R 1
0x25E6 0x0001 Thermal Model3 Event F001 R 1
0x2601 0x0001 Phase Directional1 Event F001 R 1
0x261C 0x0001 Phase Directional2 Event F001 R 1
0x2637 0x0001 Phase Directional3 Event F001 R 1
0x2653 0x0001 Neutral Directional1 Event F001 R 1
0x266F 0x0001 Neutral Directional2 Event F001 R 1
0x268B 0x0001 Neutral Directional3 Event F001 R 1
0x26A7 0x0001 Ground Directional1 Event F001 R 1
0x26C3 0x0001 Ground Directional2 Event F001 R 1
0x26DF 0x0001 Ground Directional3 Event F001 R 1
0x2708 0x0001 Breaker Failure Event F001 R 1
0x271D 0x0001 VT Fuse Failure Event F001 R 1
0x2745 0x0001 Synchrocheck Event F001 R 1
0x2774 0x0001 Recloser Event F001 R 1
0x2793 0x0001 Neutral OV1 High Event F001 R 1
0x27AE 0x0001 Neutral OV2 High Event F001 R 1
0x27C9 0x0001 Neutral OV3 High Event F001 R 1
0x27E4 0x0001 Neutral OV1 Low Event F001 R 1
0x27FF 0x0001 Neutral OV2 Low Event F001 R 1
0x281A 0x0001 Neutral OV3 Low Event F001 R 1
0x2834 0x0001 Auxiliary UV1 Event F001 R 1
0x284E 0x0001 Auxiliary UV2 Event F001 R 1
0x2868 0x0001 Auxiliary UV3 Event F001 R 1
0x2884 0x0001 Phase OV1 Event F001 R 1
0x28A0 0x0001 Phase OV2 Event F001 R 1
0x28BC 0x0001 Phase OV3 Event F001 R 1
0x28D7 0x0001 Auxiliary OV1 Event F001 R 1
0x28F2 0x0001 Auxiliary OV2 Event F001 R 1
0x290D 0x0001 Auxiliary OV3 Event F001 R 1
0x2928 0x0001 Negative Sequence TOC1 Event F001 R 1
0x2943 0x0001 Negative Sequence TOC2 Event F001 R 1
0x295E 0x0001 Negative Sequence TOC3 Event F001 R 1
0x297B 0x0001 Overfrequency1 Event F001 R 1
0x2998 0x0001 Overfrequency2 Event F001 R 1
0x29B5 0x0001 Overfrequency3 Event F001 R 1
0x29D2 0x0001 Underfrequency1 Event F001 R 1
0x29EF 0x0001 Underfrequency2 Event F001 R 1
0x2A0C 0x0001 Underfrequency3 Event F001 R 1
0x2A81 0x0001 Oscillography Event F001 R 1
0x2A9F 0x0001 Fault Report Event F001 R 1
0x2AB4 0x0001 Setting Group Event F001 R 1
0x2C0D 0x0001 Broken Conductor1 Event F001 R 1
0x2C26 0x0001 Broken Conductor2 Event F001 R 1
0x2C3F 0x0001 Broken Conductor3 Event F001 R 1
0x2E03 0x0001 Isolated Ground IOC1 Event F001 R 1
0x2E24 0x0001 Isolated Ground IOC2 Event F001 R 1
0x2E45 0x0001 Isolated Ground IOC3 Event F001 R 1
0x2E60 0x0001 Sensitive Ground Directional1 F001 R 1
0x2E7B 0x0001 Sensitive Ground Directional2 F001 R 1
0x2E96 0x0001 Sensitive Ground Directional3 F001 R 1
0x2EB5 0x0001 Forward Power1 Event F001 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
