B-58 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Funciones con Eventos habilitados - Snapshot Events Summary(cont.)
0x2ED4 0x0001 Forward Power2 Event F001 R 1
0x2EF3 0x0001 Forward Power3 Event F001 R 1
0x2F0C 0x0001 Demand Event F001 R 1
0x3000 0x0001 Board H Event F001 R 1
0x31A5 0x0001 Board J Event F001 R 1
0x32AE 0x0001 Phase TOC1 Low Event F001 R 1
0x32CB 0x0001 Phase TOC2 Low Event F001 R 1
0x32E8 0x0001 Phase TOC3 Low Event F001 R 1
0x332C 0x0001 Switchgear1 Event F001 R 1
0x332D 0x0001 Switchgear2 Event F001 R 1
0x332E 0x0001 Switchgear3 Event F001 R 1
0x332F 0x0001 Switchgear4 Event F001 R 1
0x3330 0x0001 Switchgear5 Event F001 R 1
0x3331 0x0001 Switchgear6 Event F001 R 1
0x3332 0x0001 Switchgear7 Event F001 R 1
0x3333 0x0001 Switchgear8 Event F001 R 1
0x3334 0x0001 Switchgear9 Event F001 R 1
0x3335 0x0001 Switchgear10 Event F001 R 1
0x3336 0x0001 Switchgear11 Event F001 R 1
0x3337 0x0001 Switchgear12 Event F001 R 1
0x3338 0x0001 Switchgear13 Event F001 R 1
0x3339 0x0001 Switchgear14 Event F001 R 1
0x333A 0x0001 Switchgear15 Event F001 R 1
0x333B 0x0001 Switchgear16 Event F001 R 1
0x3354 0x0001 Breaker Settings Event F001 R 1
0x3909 0x0001 Directional Power1 Event F001 R 1
0x392C 0x0001 Directional Power2 Event F001 R 1
0x394F 0x0001 Directional Power3 Event F001 R 1
0x396D 0x0001 Locked Rotor1 Event F001 R 1
0x3982 0x0001 Locked Rotor2 Event F001 R 1
0x3997 0x0001 Locked Rotor3 Event F001 R 1
0x399A 0x0001 Remote Outputs Event F001 R 1
0x3EFB 0x0001 Remote Inputs Event F001 R 1
0x4054 0x0001 Analog Comparators Event F001 R 1
0x413C 0x0001 Frequency Rate1 Event F001 R 1
0x415C 0x0001 Frequency Rate2 Event F001 R 1
0x417C 0x0001 Frequency Rate3 Event F001 R 1
0x419B 0x0001 Load Encroachment1 Event F001 R 1
0x41BA 0x0001 Load Encroachment2 Event F001 R 1
0x41D9 0x0001 Load Encroachment3 Event F001 R 1
0x44B0 0x0001 Watt Gnd Flt High 1 Event F001 R 1
0x44CB 0x0001 Watt Gnd Flt High 2 Event F001 R 1
0x44E6 0x0001 Watt Gnd Flt High 3 Event F001 R 1
0x4501 0x0001 Watt Gnd Flt Low 1 Event F001 R 1
0x451C 0x0001 Watt Gnd Flt Low 2 Event F001 R 1
0x4537 0x0001 Watt Gnd Flt Low 3 Event F001 R 1
Mapa de Usuario - User Map
0xF330 Address 00 F004 1 R 1
0xF331 Address 01 F004 1 R 1
... ... ... ... ... ... ... ...
0xF42F Address 255 F004 1 R 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
