B-60 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Ajuste Tipo de Salidas Tarjeta F (16 elementos) - Board F Output Type Settings (16 items)
0x1EB5 Output Type_F_01 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
0x1EB6 Output Type_F_02 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
... ... ... ... ... ... ... ...
0x1EC4 Output Type_F_16 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
Tiempo Pulso de Salida Tarjeta F - Board F Pulse Output Time Settings (16 items)
0x1EC5 Pulse Output Time_F_01 F005 1 R/W 2 [0 , 60000] ms
0x1EC7 Pulse Output Time_F_02 F005 1 R/W 2 [0 , 60000] ms
... ... ... ... ... ... ... ...
0x1EE3 Pulse Output Time_F_16 F005 1 R/W 2 [0 , 60000] ms
0x1EE5 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
Ajuste Rango de Entrada Analogica F (8 elementos) - Board F Analog Input Range Settings (8 items)
0x1EEA Range_F_01 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2=0 to 1 mA
3=-1 to 1 mA
4=0 to 5 mA
5=0 to 10 mA
6=0 to 20 mA
7=4 to 20 mA
0x1EEB Range_F_02 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2=0 to 1 mA
3=-1 to 1 mA
4=0 to 5 mA
5=0 to 10 mA
6=0 to 20 mA
7=4 to 20 mA
... ... ... ... ... ... ... ...
0x1EF1 Range_F_08 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2=0 to 1 mA
3=-1 to 1 mA
4=0 to 5 mA
5=0 to 10 mA
6=0 to 20 mA
7=4 to 20 mA
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
