APPENDIX B B.7 MEMORY MAP
B
Ajuste Rango de Medida de Entrada Analógica F (8 elementos) - Board F Analog Input Measurement Range (8 items)
0x1EF2 Min Value_F_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EF4 Min Value_F_02 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EF6 Min Value_F_03 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EF8 Min Value_F_04 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EFA Min Value_F_05 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EFC Min Value_F_06 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1EFE Min Value_F_07 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F00 Min Value_F_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F02 Max Value_F_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F04 Max Value_F_02 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F06 Max Value_F_03 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F08 Max Value_F_04 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F0A Max Value_F_05 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F0C Max Value_F_06 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F0E Max Value_F_07 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1F10 Max Value_F_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x1FE4 Confirmation address W 1
Ajustes Tarjeta G - Board G Settings
Ajustes de Tensión Tarjeta G - Board G Voltage Settings
0x1FE6 Voltage Threshold A_G F004 1 R/W 1 [10 , 230] V
0x1FE7 Voltage Threshold B_G F004 1 R/W 1 [10 , 230] V
0x208B Voltage Threshold C_G F004 1 R/W 1 [10 , 230] V
0x208C Voltage Threshold D_G F004 1 R/W 1 [10 , 230] V
Tiempo Antirrebotes Tarjeta G - Board G Debounce Time Settings
0x1FE8 Debounce Time A_G F004 1 R/W 1 [1 , 50] ms
0x1FE9 Debounce Time B_G F004 1 R/W 1 [1 , 50] ms
0x208D Debounce Time C_G F004 1 R/W 1 [1 , 50] ms
0x208E Debounce Time D_G F004 1 R/W 1 [1 , 50] ms
Ajuste Tipo de Entrada Tarjeta G (32 elementos) - Board G Input Type Settings (32 items)
0x1FEA Input Type_G_CC1 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
0x1FEB Input Type_G_CC2 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
... ... ... ... ... ... ... ...
0x2009 Input Type_G_CC32 F012 1 R/W 1 0=POSITIVE-EDGE
1=NEGATIVE-EDGE
2=POSITIVE
3=NEGATIVE
Ajustes Tiempo Retardo Entradas Tarjeta G (32 elementos) - Board G Delay Input Time Settings (32 items)
0x200A Delay Input Time_G_CC1 F005 1 R/W 2 [0 , 60000] ms
0x200C Delay Input Time_G_CC2 F005 1 R/W 2 [0 , 60000] ms
... ... ... ... ... ... ... ...
0x2048 Delay Input Time_G_CC32 F005 1 R/W 2 [0 , 60000] ms
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
