B-62 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Ajustes Lógica de Salidas Tarjeta G (16 elementos) - Board G Output Logic Settings (16 items)
0x204A Output Logic_G_01 F012 1 R/W 1 0=POSITIVE
1=NEGATIVE
0x204B Output Logic_G_02 F012 1 R/W 1 0=POSITIVE
1=NEGATIVE
... ... ... ... ... ... ... ...
0x2059 Output Logic_G_16 F012 1 R/W 1 0=POSITIVE
1=NEGATIVE
Ajustes Tipo de Salidas Tarjeta G (16 elementos) - Board G Output Type Settings (16 items)
0x205A Output Type_G_01 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
0x205B Output Type_G_02 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
... ... ... ... ... ... ... ...
0x2069 Output Type_G_16 F012 1 R/W 1 0=NORMAL
1=PULSE
2=LATCH
Ajustes Tiempo Pulso de Salida Tarjeta G - Board G Pulse Output Time Settings (16 items)
0x206A Pulse Output Time_G_01 F005 1 R/W 2 [0 , 60000] ms
0x206C Pulse Output Time_G_02 F005 1 R/W 2 [0 , 60000] ms
... ... ... ... ... ... ... ...
0x2088 Pulse Output Time_G_16 F005 1 R/W 2 [0 , 60000] ms
0x208A Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
Ajuste Rango de Entrada Analogica G (8 elementos) - Board G Analog Input Range Settings (8 items)
0x208F Range_G_01 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2= 0 to 1mA
3=-1 to 1mA
4= 0 to 5 mA
5= 0 to 10mA
6= 0 to 20mA
7= 4 to 20mA
... ... ... ... ... ... ... ...
0x2096 Range_G_08 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2= 0 to 1mA
3=-1 to 1mA
4= 0 to 5 mA
5= 0 to 10mA
6= 0 to 20mA
7= 4 to 20mA
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
