GE F650 - Page 632

GEK-106310AB F650 Digital Bay Controller B-63
APPENDIX B B.7 MEMORY MAP
B
Ajustes Rango de Medida de Entrada Analógica G (8 elementos) - Board G Analog Input Measurement Range Settings (8 items)
0x2097 Min Value_G_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x2099 Min Value_G_02 F003 1 R/W 2 [-9999.99 , 9999.99]
... ... ... ... ... ... ... ...
0x20A5 Min Value_G_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x20A7 Max Value_G_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x20A9 Max Value_G_02 F003 1 R/W 2 [-9999.99 , 9999.99]
... ... ... ... ... ... ... ...
0x20B5 Max Value_G_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x2189 Confirmation address W 1
Ajustes Tarjeta H (MODULO CIO) - Board H Settings (CIO MODULE)
Ajustes Tipo Tarjeta H - Board H Board Type Settings
0x2F5B I/O Board Type_H F012 1 R/W 1 0=NONE
1=16INP + 8OUT
2=8INP + 8OUT + SUPV
4=32INP
5=16INP + 8ANA
Ajustes de Tensión Tarjeta H - Board H Voltage Settings
0x2F5C Voltage Threshold A_H F004 1 R/W 1 [10 , 230] V
0x2F5D Voltage Threshold B_H F004 1 R/W 1 [10 , 230] V
0x3001 Voltage Threshold C_H F004 1 R/W 1 [10 , 230] V
0x3002 Voltage Threshold D_H F004 1 R/W 1 [10 , 230] V
Tiempo Antirrebotes Tarjeta H - Board H Debounce Time Settings
0x2F5E Debounce Time A_H F004 1 R/W 1 [1 , 50] ms
0x2F5F Debounce Time B_H F004 1 R/W 1 [1 , 50] ms
0x3003 Debounce Time C_H F004 1 R/W 1 [1 , 50] ms
0x3004 Debounce Time D_H F004 1 R/W 1 [1 , 50] ms
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
