GEK-106310AB F650 Digital Bay Controller B-67
APPENDIX B B.7 MEMORY MAP
B
Ajuste Rango de Entrada Analogica J (8 elementos) - Board J Analog Input Range Settings (8 items)
0x31AA Range_J_01 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2= 0 to 1mA
3=-1 to 1mA
4= 0 to 5 mA
5= 0 to 10mA
6= 0 to 20mA
7= 4 to 20mA
... ... ... ... ... ... ... ...
0x31B1 Range_J_08 F012 1 R/W 1 0=NONE
1=-1 to 0 mA
2= 0 to 1mA
3=-1 to 1mA
4= 0 to 5 mA
5= 0 to 10mA
6= 0 to 20mA
7= 4 to 20mA
Ajustes Rango de Medida de Entrada Analógica J (8 elementos) - Board J Analog Input Measurement Range Settings (8 items)
0x31B2 Min Value_J_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x31B4 Min Value_J_02 F003 1 R/W 2 [-9999.99 , 9999.99]
... ... ... ... ... ... ... ...
0x31C0 Min Value_J_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x31C2 Max Value_J_01 F003 1 R/W 2 [-9999.99 , 9999.99]
0x31C4 Max Value_J_02 F003 1 R/W 2 [-9999.99 , 9999.99]
... ... ... ... ... ... ... ...
0x31D0 Max Value_J_08 F003 1 R/W 2 [-9999.99 , 9999.99]
0x32A4 Confirmation address W 1
Ajustes Generales - General Settings
0x218A Phase CT Ratio F003 1 R/W 2 [1.0 , 6000.0]
0x218C Ground CT Ratio F003 1 R/W 2 [1.0 , 6000.0]
0x218E Stv Ground CT Ratio F003 1 R/W 2 [1.0 , 6000.0]
0x2190 Phase VT Ratio F003 1 R/W 2 [1.0 , 6000.0]
0x2192 Phase VT Connection F012 1 R/W 1 0=WYE
1=DELTA
0x2193 Nominal Voltage F003 1 R/W 2 [1.0 , 250.0] V
0x2195 Nominal Frequency F012 1 R/W 1 0=50 Hz
1=60 Hz
0x2196 Phase Rotation F012 1 R/W 1 0=ABC
1=ACB
0x2197 Frequency Reference F012 1 R/W 1 0=VI
1=VII
2=VIII
0x2198 Auxiliary Voltage F012 1 R/W 1 0=V
X
1=VN
0x2199 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x219B Relay Out of Sevice F012 1 R/W 1 0=DISABLED
1=ENABLED
0x219C Local/Remote Blocked F012 1 R/W 1 0=OFF
1=ON
0x2203 Confirmation address W 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
