B-68 F650 Digital Bay Controller GEK-106310AB
B.7 MEMORY MAP APPENDIX B
B
Ajustes Sobreintensidad Instantánea de Fases Nivel Alto Grupo 1 - Phase IOC High 1 Settings
0x2204 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2205 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x2206 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2208 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x220A Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x220C Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x221F Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Fases Nivel Alto Grupo 2 - Phase IOC High 2 Settings
0x2220 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2221 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x2222 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2224 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2226 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2228 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x223B Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Fases Nivel Alto Grupo 3 - Phase IOC High 3 Settings
0x223C Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x223D Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x223E Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2240 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2242 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2244 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2257 Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Fases Nivel Bajo Grupo 1 - Phase IOC Low 1 Settings
0x2258 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2259 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x225A Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x225C Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x225E Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2260 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2273 Confirmation address W 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
