GEK-106310AB F650 Digital Bay Controller B-69
APPENDIX B B.7 MEMORY MAP
B
Ajustes Sobreintensidad Instantánea de Fases Nivel Bajo Grupo 2 - Phase IOC Low 2 Settings
0x2274 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2275 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x2276 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2278 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x227A Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x227C Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x228F Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Fases Nivel Bajo Grupo 3 - Phase IOC Low 3 Settings
0x2290 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x2291 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x2292 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x2294 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2296 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x2298 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x22AB Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Neutro Grupo 1 - Neutral IOC 1 Settings
0x22AC Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x22AD Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x22AF Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x22B1 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x22B3 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x22C6 Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Neutro Grupo 2 - Neutral IOC 2 Settings
0x22C7 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x22C8 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x22CA Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x22CC Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x22CE Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x22E1 Confirmation address W 1
Ajustes Sobreintensidad Instantánea de Neutro Grupo 3 - Neutral IOC 3 Settings
0x22E2 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x22E3 Pickup Level F003 1 R/W 2 [0.05 , 160.00] A
0x22E5 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x22E7 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x22E9 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x22FC Confirmation address W 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
