APPENDIX C C.8 ANALOG INPUTS
C
a) ANALOG INPUT POINTS
POINT DESCRIPTION UNIT
0 Phasor Ia Primary kA
1 Phasor Ib Primary kA
2 Phasor Ic Primary kA
3 Phasor Ig Primary kA
4 Phasor Isg Primary kA
5 Phasor In Primary kA
6 RMS Ia Primary kA
7 RMS Ib Primary kA
8 RMS Ic Primary kA
9 RMS Ig Primary kA
10 RMS Isg Primary kA
11 I0 Primary kA
12 I1 Primary kA
13 I2 Primary kA
14 V0 Primary kV
15 V1 Primary kV
16 V2 Primary kV
17 Vab Primary kV
18 Vbc Primary kV
19 Vca Primary kV
20 Vn Primary kV
21 Va Primary kV
22 Vb Primary kV
23 Vc Primary kV
24 VL Primary kV
25 VBB Primary kV
26 Phase A Reactive Pwr MVAr
27 Phase A Apparent Pwr MVA
28 Phase A Real Pwr MW
29 Phase B Reactive Pwr MVAr
30 Phase B Apparent Pwr MVA
31 Phase B Real Pwr MW
32 Phase C Reactive Pwr MVAr
33 Phase C Apparent Pwr MVA
34 Phase C Real Pwr MW
35 3 Phase Reactive Pwr MVAr
36 3 Phase Apparent Pwr MVA
37 3 Phase Real Pwr MW
38 Phase A Power Factor
39 Phase B Power Factor
40 Phase C Power Factor
41 3 Phase Power Factor
42 Line Frequency Primary Hz
43 Bus Frequency Primary Hz
44 Vx Primary kV
45 Pos MVarhour Freeze MVArh
46 Neg MVarhour Freeze MVArh
47 Pos MWatthour Freeze MWh
48 Pos MWatthour Freeze MWh
49 Positive MVarhour MVArh
