C-22 F650 Digital Bay Controller GEK-106310AB
C.8 ANALOG INPUTS APPENDIX C
C
POINT DESCRIPTION UNIT
50 Negative MVarhour MVArh
51 Positive MWatthour MWh
52 Negative MWatthour MWh
53 Fault 1 Prefault Phase A Current Magnitude kA
54 Fault 1 Prefault Phase A Current Angle degrees
55 Fault 1 Prefault Phase B Current Magnitude kA
56 Fault 1 Prefault Phase B Current Angle degrees
57 Fault 1 Prefault Phase C Current Magnitude kA
58 Fault 1 Prefault Phase C Current Angle degrees
59 Fault 1 Prefault Phase AB Voltage Magnitude kV
60 Fault 1 Prefault Phase AB Voltage Angle degrees
61 Fault 1 Prefault Phase BC Voltage Magnitude kV
62 Fault 1 Prefault Phase BC Voltage Angle degrees
63 Fault 1 Prefault Phase CA Voltage Magnitude kV
64 Fault 1 Prefault Phase CA Voltage Angle degrees
65 Fault 1 Postfault Phase A Current Magnitude kA
66 Fault 1 Postfault Phase A Current Angle degrees
67 Fault 1 Postfault Phase B Current Magnitude kA
68 Fault 1 Postfault Phase B Current Angle degrees
69 Fault 1 Postfault Phase C Current Magnitude kA
70 Fault 1 Postfault Phase C Current Angle degrees
71 Fault 1 Postfault Phase AB Voltage Magnitude kV
72 Fault 1 Postfault Phase AB Voltage Angle degrees
73 Fault 1 Postfault Phase BC Voltage Magnitude kV
74 Fault 1 Postfault Phase BC Voltage Angle degrees
75 Fault 1 Postfault Phase CA Voltage Magnitude kV
76 Fault 1 Postfault Phase CA Voltage Angle degrees
77 Fault 1 Type Enum
78 Fault 1 Location km
79 Fault 1 Prefault Ground Current Magnitude kA
80 Fault 1 Prefault Ground Current Angle degrees
81 Fault 1 Prefault Sensitive Ground Current Magnitude kA
82 Fault 1 Prefault Sensitive Ground Current Angle degrees
83 Fault 1 Postfault Ground Current Magnitude kA
84 Fault 1 Postfault Ground Current Angle degrees
85 Fault 1 Postfault Sensitive Ground Current Magnitude kA
86 Fault 1 Postfault Sensitive Ground Current Angle degrees
87 % of Load to Trip %
88 Board F - Analog 1
89 Board F - Analog 2
90 Board F - Analog 3
91 Board F - Analog 4
92 Board F - Analog 5
93 Board F - Analog 6
94 Board F - Analog 7
95 Board F - Analog 8
96 Board G - Analog 1
97 Board G - Analog 2
98 Board G - Analog 3
99 Board G - Analog 4
100 Board G - Analog 5
101 Board G - Analog 6
102 Board G - Analog 7
