GE LOGIQ V5 Service Manual
4
of 1
of 1 rating
305 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Electrical Safety Tests Log
LOGIQ V3/V5/V5 Expert – Bas
ic Service Manual
10-35
5726264-100
English Rev.8
Peripheral 2 grou
nd
continuity
Peripheral 3 leakage
current
Peripheral 3 grou
nd
continuity
T
able
10-18:
Electrical safety tests
log (Continued)
Electrical test
performed
Max
value
allowed
V
alue
measured
OK?
Comments
T
able
10-19:
Electrical safety tests (probes) log
Probe
Max
value
allowed
Max value
measured
OK?
Comments
298
300
Table of Contents
Default Chapter
14
Certified Electrical Contractor Statement - for USA Only
14
Damage in Transportation
14
Omission and Errors
15
Service Safety Considerations
16
Copyrights
17
Legal Notes
17
Proprietary to GE
17
Trademarks
17
Table of Contents
19
Chapter 1 - Introduction
25
Overview
26
Contents in this Chapter
26
Manual Overview
27
Contents in this Manual
27
Overview
27
Typical Users of the Proprietary Service Manual
28
Purpose of Operator Manual(S)
28
LOGIQ V3/V5/V5 Expert Models Covered by this Manual
29
Important Conventions
30
Conventions Used in Book
30
Standard Hazard Icons
32
Product Icons
34
Labels Locations
35
Rating Plate Location
35
Safety Considerations
40
Contents in this Section
40
Introduction
40
Human Safety
40
Mechanical Safety
43
Electrical Safety
46
Dangerous Procedure Warnings
48
Lockout/Tagout (LOTO) Requirements
49
Returning Probes and Repair Parts
50
EMC, EMI and ESD
51
Electromagnetic Compatibility (EMC)
51
CE Compliance
51
Electrostatic Discharge (ESD) Prevention
52
Customer Assistance
53
Contact Information
53
Phone Numbers for Customer Assistance
54
System Manufacturer
54
Authorized Representative
55
Factory Site
55
Chapter 2 - Site Preparations
57
Overview
58
Contents in this Chapter
58
General Ultrasound System Requirements
59
Contents in this Section
59
Ultrasound System Environmental Requirements
59
Electrical Requirements
62
EMI Limitations
65
Probes Environmental Requirements
67
Time and Manpower Requirements
67
Facility Needs
68
Contents in this Section
68
Purchaser Responsibilities
69
Required Facility Needs
70
Desirable Features
71
Minimal Floor Plan Suggestion
72
Recommended Floor Plan Suggestion
73
Networking Setup Requirements
74
Chapter 3 - System Setup
77
Overview
78
Contents in this Chapter
78
Setup Reminders
79
Average Setup Time
79
Setup Warnings
79
Receiving and Unpacking the Equipment
82
Purpose of this Section
82
Contents in this Section
82
Warnings for Receiving and Unpacking
82
LOGIQ V3/V5/V5 Expert Transportation Box Label
83
Unpacking the LOGIQ V3/V5/V5 Expert
84
Packing the Equipment
88
Preparing for Setup
89
Verify Customer Order
89
Physical Inspection
89
EMI Protection
89
Completing the Setup
90
Purpose of this Section
90
Contents in this Section
90
System Specifications
90
Completing the Setup
91
Electrical Specifications
92
Connecting Cables
93
Peripherals/Accessories Connector Panel
94
Connections on the I/O Rear Panel
96
Connecting Probes
96
Powering the System
96
System Configuration
97
Purpose of this Section
97
LOGIQ V3/V5/V5 Expert Configuration
97
Peripherals Installation
102
Overview
102
Furnished Materials
103
Peripherals Installation Instructions
105
Option Setup
120
Software Option Installation Procedure
120
Paperwork after Setup
123
Contents in this Section
123
User's Manual(S)
123
Product Locator Installation Card
123
Chapter 4 - General Procedures and Functional Checks
125
Overview
126
Purpose of this Chapter
126
Contents in this Chapter
126
Special Equipment Required
126
General Procedures
127
Overview
128
Power On/Boot up
129
Power off
132
Check System Date and Time
134
Manufacturer
135
Removable Media
135
Functional Checks
145
Overview
145
Contents in this Section
145
Preparation
145
Basic Controls
146
Control Panel
146
LOGIQ V5/LOGIQ V3 Softmenu Key Tour
147
Control Panel
148
Performance Tests
149
Mode (B Mode) Checks
150
Mode Screen Example
150
Preparations
150
Adjust the 2D Mode Controls
150
Image Quality Check (IQC) Preset for Service
151
M Mode Checks
153
M-Mode Screen Example
153
Preparations
153
Adjust the M Mode Controls
153
Color Mode Checks
154
Select Color 2D Mode
154
Adjust the Color Mode Controls
155
Select Color M Mode
156
PW Doppler Mode Checks
158
Adjust the PW Doppler Mode Controls
159
Tissue Velocity Imaging (TVI) Checks
160
Adjust the TVI Controls
161
Basic Measurements
162
Probe/Connectors Check
163
ECG Check
165
Cineloop Check
166
Preparation
166
Adjust the Cineloop Controls
166
Back End Processor Checks
166
Operator Panel Test
167
Peripheral Checks
167
Turn off Power to LOGIQ V3/V5/V5 Expert
167
Mechanical Functions Checks
167
Application Turnover Check List
169
Software Configuration Checks
169
Site Log
170
My Trainer
171
Overview
171
Chapter 5 - Components and Functions (Theory)
175
Overview
176
Contents in this Chapter
176
Block Diagram and Theory
177
Block Diagram
177
Introduction
178
Chapter 6 - Service Adjustments
181
Overview
182
Contents in this Chapter
182
LCD Monitor Adjustments
183
Purpose of this Section
183
Chapter 7 - Diagnostics/Troubleshooting
189
Overview
190
Contents in this Chapter
190
Gathering Trouble Data
191
Overview
191
Collect Vital System Information
191
Collect a Trouble Image with Logs
192
Screen Capture
193
Capturing a Screen
194
Capturing a Screen with Service Dongle
197
Global Service User Interface (GSUI)
200
Enter Global Service User Interface
200
Control Frame
203
Common Diagnostics
204
Network and Insite II Configuration
217
Network Configuration
217
Chapter 8 - Replacement Procedures
223
Overview
224
Warnings and Important Information
225
Warnings
225
Returning/Shipping Probes and Repair Parts
226
Loading the Software
227
Purpose of this Section
227
Customer Provided Prerequisite
227
Data Management - Moving All Images
227
Backing up the Patient Archive and System Configurations
228
Restoring up the Patient Archive and System Configurations
228
Recording Important Settings and Parameters
229
Loading the System Software
230
Rewrite the Serial Number
244
Chapter 9 - Renewal Parts
253
Overview
254
Contents in this Chapter
254
List of Abbreviations
255
Renewal Parts Lists
256
Operator Console Assy
256
Probe
257
Peripheral
257
Power Cord
260
Manuals
261
Chapter 10 - Care and Maintenance
265
Overview
266
Contents in this Chapter
266
Warnings
267
Why Do Maintenance
268
Periodic Maintenance Inspections
268
Keeping Records
268
Quality Assurance
269
Maintenance Task Schedule
270
How Often Should Maintenance Tasks be Performed
270
Tools Required
272
Standard GE Tool Kit
272
Tool Kit
274
Special Tools, Supplies and Equipment Used for Maintenance
275
System Maintenance
276
Preliminary Checks
276
Functional Checks
277
Physical Inspection
279
Optional Diagnostic Checks
280
Probe Maintenance
281
Electrical Safety Tests
283
Safety Test Overview
283
Leakage Current Limits
285
Outlet Test - Wiring Arrangement
287
Grounding Continuity
288
Chassis Leakage Current Test
289
Probe Leakage Current Test
291
When There's too Much Leakage Current
294
AC/DC Fails
294
Chassis Fails
294
Probe Fails
295
Peripheral Fails
295
Still Fails
295
New Unit
295
ECG Fails
295
Inspection Paperwork
296
Ultrasound Inspection Forms
296
Electrical Safety Tests Log
298
