GE MAC 2000 Service Manual

TechnicalSpecications
Electrical
Item
Specications
Powersupply
InternalAC/DCorbatteryoperation
Inputvoltage
100–240VAC±10%
Inputcurrent
(Maximumpower
consumption)
1.5Aat115Vto230VAC
Inputfrequency
47–63Hz
SafetyrequirementIEC60601–1protectionclassI
Fuserequirement
PhaseandneutralmeetUL/IECrequirements
Powerinletsocket
IECC14type
Battery
Item
Specications
Type
Replaceableandrechargeable,LithiumIon
Capacity
14.4V,2.2AH±10%
100singlepagerestingECGrecordingor3hours(typical)of
continuousmonitoringwithoutprinting(minimum)
ChargetimeApproximately3.5hoursfromtotaldischarge(withdeviceoff)
Acquisition,Processing,andPerformance
LEDs
Item
Specications
BatterychargingSteadyamber:Batterycharging
Flashingamber:batterylow
Off:batteryfullycharged(whenconnectedtoACMains);neither
chargingnorlow(whenrunningonbattery)
ExternalpowerSteadygreen:externalpowerconnected
Off:noexternalpower
ECGDataAcquisition
Item
Specication
ECGfrontendInternalECGfrontendwithDSP
provides10simultaneouslysampledelectrodechannels
Signalinput
TypeCF
Amplituderesolution
4.88µV±1%perLSB@500SPS
Dynamicrange
ACdifferential:±5mV
DCoffset:±300mV
Frequencyrange
0.04to150Hz
2053535-003C
MAC™2000ECGAnalysisSystem
173

GE MAC 2000 Specifications

General

ECG Type	Resting ECG
Number of Channels	12
Report Format	PDF, XML
Battery Type	Rechargeable lithium-ion
Connectivity	Ethernet
Data Storage	Internal memory
Display	High-resolution color LCD
Power Supply	Universal AC power supply
