GE MAC 2000 Service Manual

ServiceSetup
5.Whenthetestisdone,pressEscorCancel.
Thefollowingwindowopens:
6.Dooneofthefollowing,dependingontheresultsofthetest:
•Ifthetestpassed,pressYes
•Ifthetestfailed,pressNo.
ReplacethemainPWAasdescribedin“PWA”onpage120.
TestingthePatientLeadwires
Usethefollowingproceduretotestthepatientleadwires:
1.OpentheDiagnosticTestswindowasdescribedin“SystemDiagnostics”on
page46.
2.Connectapatientcablewithleadwirestothedevice’spatientcableconnector.
3.Connectallleadstoapatientsimulatororshortingbar.
4.SelectPatientLeadWireCheck.
Thefollowingwindowopens:
5.PressEntertoselectStartTest.
Thetestresultsaredisplayedforeachleadwire.
•Ifthefollowingmessageisdisplayed,theleadwirepassedthetest:
Connected.
•Ifthefollowingmessageisdisplayed,theleadwirefailedthetest:
Disconnected.
6.Whenthetestisdone,pressEscorCancel.
2053535-003C
MAC™2000ECGAnalysisSystem
59

GE MAC 2000 Specifications

General

ECG Type	Resting ECG
Number of Channels	12
Report Format	PDF, XML
Battery Type	Rechargeable lithium-ion
Connectivity	Ethernet
Data Storage	Internal memory
Display	High-resolution color LCD
Power Supply	Universal AC power supply
