GE MAC 2000 Service Manual

Maintenance
Printer
Thefollowingproceduresdescribehowtoreplacetheprintermoduleassembly,the
printermotorandgearassembly,thepapersensor,theprinthead,theprinterdoor,
andtheprinterdoorsensor.
PrinterModuleAssembly
Thefollowingproceduresdescribehowtoremoveandreplacetheprintermodule
assembly.
RemovingthePrinterModuleAssembly
Usethefollowingproceduretoremovetheprintermoduleassembly.
1.Beforebeginninganysteps,followtheinstructionsin“PreparingtheSystemfor
FRUReplacement”onpage73.
2.Removethetopcoverassembly,ifitishasnotbeenremovedalready.
See“RemovingtheTopCoverAssembly”onpage75formoreinformation.
3.Detachthechassis.
See“DetachingtheChassis”onpage82forinstructions.
4.Removethefour(4)screwssecuringtheprintermoduleassemblytothebottom
cover.
Thelocationsofthefour(4)screwsareapproximatelyidentiedinthefollowing
photograph.
5.Lifttheprintermoduleassemblytoremoveit.
94
MAC™2000ECGAnalysisSystem
2053535-003C
