GE MAC 2000 Service Manual

Maintenance
RemovingthePowerInletModule
Usethefollowingproceduretoremovethepowerinletmodule.
1.Beforebeginninganysteps,followtheinstructionsin“PreparingtheSystemfor
FRUReplacement”onpage73.
2.Removethetopcoverassembly,ifitishasnotbeenremovedalready.
See“RemovingtheTopCoverAssembly”onpage75formoreinformation.
3.Detachthechassis.
See“DetachingtheChassis”onpage82forinstructions.
4.RemovethetwoM3x8screwssecuringthepowerinletmoduletothebottom
cover,asshowninthefollowingphotograph.
5.Removethepowerinletmodule.
ReplacingthePowerInletModule
Usethefollowingproceduretoreplacethepowerinletmodule.
1.Positionthepowerinletmoduleinthebottomcover.
2.SecurethepowerinletmoduletothebottomcoverusingtwoM3x8screws,as
showninthefollowingphotograph.
3.Reattachthechassis.
Seestep1throughstep6in“AttachingtheChassis”onpage85forinstructions.
4.Reattachthetopcoverassembly.
See“ReattachingtheTopCoverAssemblytotheDevice”onpage81for
instructions.
5.Reinsertthebattery.
Seestep6throughstep8in“ReplacingtheBattery”onpage74forinstructions.
6.ContinuewiththeappropriatefunctionalcheckoutprocedureforthisFRU.
See“FunctionalCheckout”onpage129formoreinformation.
2053535-003C
MAC™2000ECGAnalysisSystem
93
