Maintenance
8.Turnoverthetopcoverassemblyandsecurethedisplayassemblytothetop
coverusingthesixfastenersshowninthefollowingphotograph.
Thetopcoverassembly,withthedisplayassemblymountedonit,isnow
completelyreassembled,asshowninthefollowingphotograph.
9.Proceedto“ReattachingtheTopCoverAssemblytotheDevice”onpage81.
ReattachingtheTopCoverAssemblytotheDevice
Usethefollowingproceduretoreattachthetopcoverassemblytothedevice.
1.Lineupthetopcoverassemblytothedevice,asshowninthefollowing
photograph.
2.Gentlylowerthetopcoverassemblypartwayandconnectthedisplaycable(1)
andkeypadribbon(2)tothePWA,asshowninthefollowingphotograph.
2053535-003C
MAC™2000ECGAnalysisSystem
81
