4.TurnoverthetopcoverandinserttheO-ringintothegrooveonthetopcover,as
showninthefollowingphotograph.
5.Alignthetabsonthedisplaybottomcoverwiththeslotsonthedevicetopcover,
asindicatedinthefollowingphotograph.
6.Lowerthedisplaybottomcovertowardthedevicetopcoverandcarefully
threadthedisplaycableandkeypadribbonthroughtheslotsonthetopcover.
7.Lowerthedisplayassemblyontothetopcoverandgentlyslidethedisplay
assemblytowardthebackofthetopcoverassembly,asshowninthefollowing
photograph.
80
MAC™2000ECGAnalysisSystem
2053535-003C
